| 1. | 87658572 | [1] | CONTROL VALVE | BUR3 Spool; See Figure 08-15 For Service |
| 1. | 87658573 | [1] | CONTROL VALVE | BUR4 Spool; See Figure 08-18 For Service |
| 2. | 87636980 | [1] | HYD CONNECTOR | BURCONNECTOR, HYD., Elbow, 45 Degree |
| 3. | 72109077 | [1] | HYD CONNECTOR | SMElbow, 90 Degree |
| 4. | 87588715 | [1] | HOSE,19.05mm ID x 3460mm L | BURHOSE, From Top Valve Port to Bottom Tee; 3460 mm (136 - 1/4 in) |
| 6. | 242999A1 | [3] | CLAMP | CASDouble |
| 7. | 895-11012 | [2] | WASHER,13.5mm ID x 24mm OD x 2.5mm Thk | CAS |
| 8. | 825-1412 | [2] | NUT,M12, Cl 8 | CAS Superseded by part number: 9706685 |
| 9. | 14496621 | [4] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | TTF |
| 10. | 627-10030 | [8] | BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd | CAS Superseded by part number: 9515003 |
| 11. | 627-12030 | [1] | BOLT,Hex, M12 x 1.75 x 30mm, Cl 10.9, Full Thd | IH Superseded by part number: 43260 |
| 12. | 825-1410 | [1] | NUT,M10, Cl 8 | CAS Superseded by part number: 100016 |
| 13. | 87603188 | [1] | BRACKET | BURBRACKET, For Hoses |
| 14. | 79076680 | [1] | CLAMP | LEC |
| 15. | 627-10040 | [1] | BOLT,Hex, M10 x 1.5 x 40mm, Cl 10.9, Full Thd | CAS Superseded by part number: 43248 |
| 16. | 87637725 | [1] | HOSE,15.88mm ID x 820mm L | BURHOSE, Connects at Bottom Tee with Ref 4 and At Elbow with Ref 21; 820 mm (32 - 5/16 in) |
| 18. | 78100053 | [2] | HYD CONNECTOR | LECTee |
| 19. | 78100066 | [4] | HYD CONNECTOR | LECConnects to the Tee, Elbow |
| 20. | 87588717 | [2] | HYDRAULIC HOSE,15.88 mm ID x 700.00 mm, SAE 100R2 | BURFrom Top Elbow to Lift Cylinder |
| 21. | 87588716 | [2] | HYDRAULIC HOSE,15.88 mm ID x 810.00 mm, SAE 100R2 | BURFrom Bottom Elbow to Lift Cylinder |
| 22. | 87674696 | [2] | LIFT CYLINDER | BURCYLINDER, LIFT, See Figure 08-22 for Service Superseded by part number: 76043960 |
| 22. | 76043960R | [2] | REMAN-HYD CYLINDER | TORD150B TIER 3 (HYDRO) (10/07-), Reman for New PN 87674696 |
| 22. | 76043960C | [2] | CORE-HYD CYLINDER | TORReturn Number |
| 23. | 14453381 | [6] | O-RING,0.07" Thk x 0.614" ID, -16, Cl 7, 75 Duro | MKT Superseded by part number: 5135734 |
| 24. | 87617248 | [2] | CLAMP | BURBRACKET |
| 25. | 85700654 | [2] | WASHER,10.5mm ID x 20mm OD x 2.5mm Thk | BAS |
| 26. | 627-10020 | [2] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9, Full Thd | CAS Superseded by part number: 11106031 |
| 27. | 87616860 | [1] | HYD. TUBE,14 mm ID x 16 mm OD | BURTUBE, RIGID |
| 28. | 87694650 | [2] | LINKAGE YOKE | BHBYOKE, Assy., Incl. Ref. 29, 30 |
| 29. | 8271634 | [2] | BUSHING,50mm ID x 62mm OD x 44mm L | LEC |
| 30. | 87556906 | [4] | BOLT,Hex, M14 x 70mm, Cl 10.9 | WIC |
| 31. | 79092893 | [2] | SEAL | LEC |
| 32. | 12626201 | [6] | WASHER,10.2mm ID x 25mm OD x 3mm Thk | LEC Superseded by part number: 12626221 |
| 33. | 76069715 | [2] | TIE-ROD | TOR |
| 34. | 76069717 | [2] | HOSE CLIP | LEC |
| 35. | 8283916 | [4] | RING | LEC |
| 36. | 895-11014 | [4] | WASHER,M14 x 28 x 2.5 | IH Superseded by part number: 87016605 |
| 37. | 87357989 | [4] | BOLT,M14 x 1.5 x 38.9mm OAL, Cl 8.8, Full Thd | WIC |
| 38. | 87693643 | [2] | PLATE, COVER | |
| 39. | 87693638 | [2] | PIN | |
| 40. | 87616861 | [1] | HYD. TUBE,14 mm ID x 16 mm OD x 896.5, 75 mm L | BURTUBE, RIGID Lifting |
