现代零件查询16/18/20B-7 TILT CYLINDEREPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
977 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31FY-08000
|
[1] |
CYLINDER ASSY
|
|
| 1. |
31Y3-27000
|
[1] |
TUBE ASSY
|
|
| 2. |
31Y3-27050
|
[1] |
ROD
|
|
| 3. |
31Y3-27060
|
[1] |
GLAND
|
|
| 4. |
S731-030030
|
[1] |
DU BUSHING
|
|
| K5. |
Y200-030011
|
[1] |
SEAL-ROD
|
|
| K6. |
Y180-030020
|
[1] |
RING-BACK UP
|
|
| K7. |
Y110-030011
|
[1] |
WIPER-DUST
|
|
| 8. |
Y190-042000
|
[1] |
RING-SNAP
|
|
| K9. |
S632-065004
|
[1] |
O-RING
|
|
| K10. |
S642-065003
|
[1] |
RING-BACK UP
|
|
| 11. |
31YC-67080
|
[1] |
WASHER-LOCK
|
|
| K12. |
S632-070001
|
[1] |
O-RING
|
|
| 13. |
31Y3-27070
|
[1] |
PISTON
|
|
| K14. |
Y430-070100
|
[1] |
SEAL-PISTON
|
|
| K15. |
Y300-070100
|
[1] |
RING-WEAR
|
|
| K16. |
S631-021004
|
[1] |
O-RING
|
|
| 17. |
31YC-65130
|
[1] |
NUT-NYLON
|
|
| 18. |
31Y3-18950
|
[1] |
EYE-ROD
|
|
| 19. |
31Y3-16750
|
[1] |
BEARING-SPHERICAL
|
|
| 20. |
S017-120502
|
[1] |
BOLT-HEX HEAD
|
|
| 21. |
S205-121002
|
[1] |
NUT-HEX
|
|
| 22. |
S411-120002
|
[1] |
WASHER-SPRING
|
|
| 23. |
S731-035040
|
[1] |
DU BUSH
|
|
| 24. |
S651-810002
|
[3] |
NIPPLE-GREASE
|
|
| K25. |
S621-011001
|
[2] |
O-RING
|
|
| K. |
31Y3-27080
|
[1] |
SEAL KIT
|
|
