神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (08-002) - GOVERNOR ASSY Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
515 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VG47540Z0005 | [1] | GOVERNOR ASSEMBLY | GOVERNOR ASSEMBLY |
| 1. | VG47541Z9003 | [1] | BODY COMPLETE | |
| 3.4. | VG47542Z9000 | [1] | PISTON COMPLETE (INC. KEY NO.18) | |
| 4. | VG47543Z9000 | [1] | O RING | |
| 5. | VG47544Z9000 | [1] | VALVE | |
| 6. | VG47545Z9000 | [1] | VALVE SPRING | |
| 7. | VG47543Z9001 | [2] | O RING | |
| 8. | VG47546Z9000 | [1] | EXHAUST STEM | |
| 9. | VG47547Z9000 | [1] | EXHAUST STEM | |
| 10. | VG47548Z9000 | [1] | ADJUSTING SCREW | |
| 16. | VG47549Z9003 | [1] | RETAINING RING | |
| 17. | VG47550Z9000 | [1] | COVER | |
| 18. | NSS | [1] | NOT SOLD SEPARAT | CONWASHER |
