凯斯零件查询(RBX341) - CASE IH ROUND BALER (9/02-12/05) (15.01[01]) - TWINE ARM Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
442 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84024684
|
[1] |
SUPPORT
|
PLO
|
| 2. |
100016
|
[11] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 3. |
80140045
|
[1] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 4. |
80120109
|
[4] |
SCREW
|
ZED
M10x20 Superseded by part number: 43138
|
| 5. |
84024676
|
[1] |
SUPPORT
|
PLO
|
| 6. |
80120041
|
[2] |
CARRIAGE BOLT
|
ZED
M10x20 Superseded by part number: 120041
|
| 7. |
80130003
|
[2] |
COTTER PIN
|
ZED
Superseded by part number: 130003
|
| 8. |
80378245
|
[2] |
WASHER
|
ZED
12MM Superseded by part number: 378245
|
| 9. |
84017216
|
[1] |
PIN,12.7mm OD x 64.5mm L
|
ZED
|
| 10. |
16043224
|
[2] |
BOLT,Hex, M8 x 16mm, Cl 8.8
|
NH
|
| 11. |
84024808
|
[2] |
CLAMP,51mm ID, 9mm Bolt Hole, P Type
|
PLO
|
| 12. |
89843435
|
[1] |
ACTUATOR
|
PLO
Superseded by part number: 9843435
|
| . . |
9843435R
|
[1] |
REMAN-ELECTRIC ACTUATOR
|
NH
RBX341 (9/02-), RBX341 SILAGE PACK (3/03-), Reman for New P/N 89843435
|
| . . |
9843435C
|
[1] |
CORE-ELECTRIC ACTUATOR
|
NH
Return Number
|
| 13. |
84025507
|
[1] |
COVER PLATE
|
PLO
|
| 14. |
80322358
|
[2] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 15. |
43362
|
[2] |
NUT,M8 x 1.25, Cl 10
|
BHB
|
| 16. |
84024672
|
[1] |
SUPPORT
|
PLO
|
| 17. |
80120111
|
[5] |
SCREW
|
ZED
M10x30 Superseded by part number: 43140
|
