神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (01-011) - CYLINDER BLOCK, (FITTING PARTS), CAMCHAMBER COVER Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
951 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | A3 | [1] | 43,46,51,55,81 | |
| . . | A4 | [1] | 56 | |
| . . | A6 | [1] | 41,70,71,73,76 | |
| 1.2. | VG1212196004 | [6] | OIL INJECTOR JET ASSY-OIL, Start Year: 01-JAN-85 | OIL INJECTOR JET ASSY-OIL, Start Year: 01-JAN-85 |
| 1.2. | VG1212196002 | [6] | JET ASSY-OIL | |
| 2. | VG0152206124 | [6] | PIN-STRAIGHT | |
| 3. | VG1212396000 | [6] | SCREW | KOBBOLT ASSY |
| 4. | VG1513096002 | [1] | VALVE VALVE ASSY, Start Year: 01-DEC-82 | VALVE VALVE ASSY, Start Year: 01-DEC-82 |
| 4. | VG1513096000 | [1] | VALVE ASSY VALVE ASSY | VALVE ASSY VALVE ASSY |
| 5. | VG0893144410 | [1] | PLUG PLUG-STRAIGHT | PLUG PLUG-STRAIGHT |
| 6. | VG0135121144 | [1] | GASKET | KOBGASKET |
| 7. | VG1103896000 | [1] | COVER | |
| 8. | VG1521196000 | [1] | GASKET | KOBGASKET |
| 9. | VG0811102562 | [4] | BOLT,W/WASHER | |
| 10. | VG1102996007 | [1] | REF TO 93PB032 COVER-CAMCHAHBER (FOR A3) | REF TO 93PB032 COVER-CAMCHAHBER (FOR A3) |
| 10. | VG1102996017 | [1] | COVER-CAMCHAMBER (FOR A6) | |
| 10. | VG1102996010 | [1] | COVER-CAMCHAMBER (FOR A4) | |
| 11. | VG1103396000 | [1] | GASKET-COVER GASKET-COVER | GASKET-COVER GASKET-COVER |
| 12. | VG1103096000 | [1] | COVER-CAMCHAMBER (FOR A6) | |
| 12. | VG1103096006 | [1] | COVER COVER-CAMCHAMBER (FOR A3,A4) | COVER COVER-CAMCHAMBER (FOR A3,A4) |
| 13. | VG1103396000 | [1] | GASKET-COVER GASKET-COVER | GASKET-COVER GASKET-COVER |
| 14. | VG0812081628 | [24] | BOLT, W/WASHER (FOR A3,A4), Start Year: 01-APR-85 | |
| 14. | VG0811081662 | [24] | BOLT BOLT, W/WASHER (FOR A3,A4) | BOLT BOLT, W/WASHER (FOR A3,A4) |
