凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (01.01[01]) - POWER TAKE-OFF Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
515 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
84068652
|
[1] |
PTO
|
PLO
(1 to 27 and fig.01.02)
|
| . . |
84053419
|
[1] |
PTO SHAFT
|
PLO
, Serial Range: (1,11-23)
|
| . . |
84053420
|
[1] |
PTO SHAFT
|
PLO
(2,22,24 to 27 and fig.01.02)
|
| 1. |
84053421
|
[1] |
PROTECTING COVER
|
PLO
, Serial Range: (3-6)
|
| 2. |
84053422
|
[1] |
PROTECTING COVER
|
PLO
, Serial Range: (4,6-10)
|
| 3. |
80734264
|
[1] |
SPIDER
|
PLO
(17) Superseded by part number: 84355336
|
| 4. |
80411728
|
[2] |
RING
|
ZED
Superseded by part number: 411728
|
| 5. |
80853558
|
[1] |
SHIELD
|
PLO
(6) Superseded by part number: 853558
|
| 6. |
80321803
|
[8] |
BOLT
|
ZED
M4x10 Superseded by part number: 72181877
|
| 7. |
80277860
|
[1] |
BEARING ASSY
|
PLO
Superseded by part number: 277860
|
| 8. |
80456570
|
[1] |
REINFORCEMENT
|
ZED
|
| 9. |
84043771
|
[1] |
SHIELD
|
PLO
(6)
|
| 10. |
80379650
|
[1] |
CHAIN
|
ZED
Superseded by part number: 87586692
|
| 11. |
89602979
|
[1] |
CHAIN
|
ZED
Superseded by part number: 700713239
|
| 12. |
89602980
|
[1] |
GUARD
|
PLO
Superseded by part number: 700056030
|
| 13. |
89602981
|
[1] |
RING
|
PLO
Superseded by part number: 9602981
|
| 14. |
80853570
|
[1] |
YOKE
|
PLO
(15) Superseded by part number: 853570
|
| 15. |
80744051
|
[1] |
KIT
|
ZED
Superseded by part number: 744051
|
| 16. |
84043766
|
[2] |
SPIDER
|
PLO
(17,18)
|
| 17. |
150024
|
[3] |
LUBE NIPPLE,45 Degree, M8 x 1
|
NH
|
| 18. |
80853562
|
[4] |
DISC
|
PLO
Superseded by part number: 853562
|
| 19. |
84043767
|
[1] |
YOKE
|
PLO
(20)
|
| 20. |
80300919
|
[1] |
LUBE NIPPLE,M8 x 1
|
ZED
Superseded by part number: 84447449
|
| 21. |
84043768
|
[1] |
YOKE
|
PLO
Superseded by part number: 9805825
|
| 22. |
80440437
|
[2] |
PIN
|
PLO
Superseded by part number: 440437
|
| 23. |
84043769
|
[1] |
TUBE
|
PLO
|
| 24. |
84043770
|
[1] |
TUBE
|
PLO
Superseded by part number: 84053423
|
| 25. |
80734265
|
[1] |
YOKE
|
PLO
Superseded by part number: 734265
|
