| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 87652974 | [2] | CHAIN ASSY, Painted Gray; 45 Link Extended Life Track (CELT) 24 inch 1 Bar Open; Incl (1) 87582757 Chain Assy; Incl Ref 1 - 22 | |
| . . | 87582757 | [1] | CHAIN ASSY, Unpainted; 45 Link CELT 24 in 1 Bar Open; Incl. (1) 87582752 Chain Assy; Incl Ref 1 - 22 | |
| . . | 87582752 | [1] | TRACK CHAIN | BURCHAIN ASSY, Unpainted; 45 Link CELT; Incl Ref 1 - 15 |
| 1. | 87582720 | [44] | TRACK LINK | BURRight Hand Track Link |
| 2. | 87582719 | [44] | TRACK LINK | BURLeft Hand Track Link |
| 3. | 87582715 | [45] | BUSHING,38.45mm ID x 65mm OD x 131.4mm L | BURBushing |
| 4. | 87567383 | [45] | BUSHING | BURBushing, Rotating |
| 5. | 87582716 | [45] | LARGE PIN | BURPIN, LARGE Pin |
| 6. | 87582717 | [90] | THRUST RING | BURThrust Ring |
| 7. | 87582727 | [90] | SEAL,55mm ID x 63mm OD x 10.7mm Thk | BURSeal |
| 8. | 87582718 | [45] | PLUG | BUROil Plug |
| . . | 87582786 | [1] | TRACK LINK | BURMASTER LINK, Service, Right Hand, Replaces 87582722 Link Used In Production; Incl Ref 9, 10 |
| 9. | NSS | [1] | NOT SERVICED SEPARATELY | CONLink, Fits Over Track Pin on Outside of Regular Track Link |
| 11. | 87582725 | [2] | BOLT | BUR3/4 NF x 75 mm Special Bolt |
| 12. | 87582724 | [2] | BOLT | BUR3/4 NF x 99.3 mm Special Bolt |
| . . | 87624375 | [1] | TRACK LINK | BURMASTER LINK, Service, Left Hand, Replaces 87582721 Link Used In Production; Incl Ref 14, 15; Not Illustrated |
| 19. | 87582772 | [1] | TRACK SHOE | BURShoe, Track, Master, 610 mm (24 in) 1 Bar Open |
| 19. | 87582748 | [44] | TRACK SHOE | BURShoe, Track, 610 mm (24 in) 1 Bar Open |
| 20. | 87582726 | [176] | BOLT | BUR3/4 NF x 60.4 mm Special Bolt; Quantity is for One Side |
| 21. | 87582723 | [176] | SQUARE NUT | BUR3/4 NF Square Nut; Quantity is for One Side |
| 22. | 345-49 | [1] | SEALANT | CASAdhesive, 1 ml Loctite 242; Master Link Bolts; Not Illustrated Superseded by part number: NLS |
