纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (5.651[01]) - ROPS CANOPY DC70 - DC80 - DC100 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
577 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76598299 | [1] | ROPS | MACSUN CANOPY |
| 2. | 76591395 | [4] | NUT | MAC- SELF-LOCKING NUT |
| 3. | 76591396 | [4] | SCREW | MAC |
| 4. | 76591397 | [1] | WIRE HARNESS | MACHARNESS, Lights, Front End |
| 5. | 76591398 | [6] | HEADLAMP | MACFLOODLIGHT |
| 6. | 76591399 | [1] | CEILING LAMP | MACCEILING LAMP |
| 7. | 76591400 | [1] | BULB | MACLAMP Superseded by part number: 10863090 |
| 9. | 76591401 | [8] | WASHER | MAC |
| 10. | 76591402 | [4] | SILENTBLOC | MACDAMPENER |
| 11. | 76605375 | [1] | INSULATING PANEL | MACDEADENING |
| 12. | 76591404 | [1] | UTILITY HOLDER | MACCOAT HOOK |
| 13. | 76590749 | [2] | SCREW | MAC Superseded by part number: 86508568 |
| 14. | 76598300 | [2] | LOCK WASHER | MACLOCK |
| 15. | 54004017 | [6] | BULB | BHBLAMP Superseded by part number: 154004017 |
| 16. | 76610455 | [4] | FASTENER | MACRETAINER PIN |
