神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (07-008) - MOTOR-STARTING, (INNER PARTS), (SAWAFUJI MAKE) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
691 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-36. | VG2330096062 | [1] | MOTOR-STARTING | |
| 1-36. | VG2330096064 | [1] | MOTOR-STARTING (FOR A2) | |
| 2. | VG2330699202 | [2] | COIL | KOBCOIL ASSY-FIELD |
| 3-6. | VG2333799112 | [1] | U-BRACKET | KOBREAR |
| 3-5. | VG2333099107 | [1] | HOLDER, INJECTOR NOZ | KOBBRUSH |
| 4. | VG2333399011 | [4] | SPRING | KOB |
| 5. | VG2337999015 | [4] | BRUSH | KOB |
| 6. | VG2333799113 | [1] | U-BRACKET | KOBREAR |
| 10-12. | VG2331099114 | [1] | ARMATURE ASSY (FOR A1) | ARMATURE ASSY (FOR A1) |
| 10-12. | VG2331099117 | [1] | ARMATURE | KOB(FOR A2) |
| 11. | VG2338399113 | [1] | BALL BEARING | KOBREAR (FOR A1) |
| 11. | VG2338399117 | [1] | BALL BEARING | KOBREAR (FOR A2) |
| 12. | VG2338399116 | [1] | BALL BEARING | KOBFRONT (FOR A1) |
| 12. | VG2338399118 | [1] | BALL BEARING | KOBFRONT (FOR A2) |
| 13. | VG2334099115 | [1] | BOLT | |
| 14. | VG2334099116 | [1] | BOLT | BOLT |
| 15. | VG2331899203 | [1] | CASE, STARTER | CASE, STARTER |
| 16. | VG2334899003 | [1] | SHAFT | KOB |
| 17. | VG2332899001 | [1] | SHIM | KOB |
| 18. | VG2332899002 | [1] | SHIM | |
| 19.2. | VG2331799003 | [1] | BRACKET ASSY-CENTER | |
| 20. | VG2344199017 | [1] | SCREW | KOBBUSH |
| 21. | VG2334499010 | [1] | O-RING | KOB |
| 22. | VG2332299106 | [1] | ARM LEVER ASSY | ARM LEVER ASSY |
| 23. | VG2332399004 | [1] | BOLT | |
| 24. | VG2330799000 | [1] | PLATE-LOCK | |
| 25. | VG2331399115 | [1] | SET OF PINIONS | KOBASSY |
| 26. | VG2336999016 | [1] | STOP | KOBPINION |
| 27.28. | VG2331899204 | [1] | CONDENSER CASE ASSY-PINION | CONDENSER CASE ASSY-PINION |
| 28. | VG2331999014 | [1] | BUSHING | KOB |
| 29. | VG2334199012 | [1] | COVER | KOB |
| 30. | VG2332399005 | [2] | SCREW | KOB |
| 31. | VG2330899000 | [1] | SWITCH | KOB |
| 32. | VG2332399006 | [2] | BOLT | |
| 33. | VG2332899003 | [1] | SHIM | |
| 34. | VG2334199010 | [1] | COVER | KOB Superseded by part number: VG2334199109 |
| 35. | VG2334799012 | [1] | BAR | KOBCONNECT |
| 36. | VG2330999000 | [2] | CAP | KOB |
