神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (05-002) - NOZZLE & HOLDER, (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
818 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-15. | VG1660096502 | [6] | NOZZLE | KOBNOZZLE & HOLDER (FOR A1) |
| 1-15. | VG1660096505 | [6] | NOZZLE & HOLDER (FOR A2) | |
| 1-15. | VG1660096511 | [6] | HOLDER, INJECTOR NOZ | KOB(FOR A3) |
| 1-12. | VG1661096002 | [6] | HOLDER, INJECTOR NOZ | KOB |
| 2. | VG1661296000 | [6] | PUSH ROD | KOBPUSH |
| 3. | VG1661396000 | [6] | SPRING | KOB |
| 4. | VG1661690001 | [6] | SCREW ADJUSTING | SCREW ADJUSTING |
| 5. | VG1660996000 | [6] | PIN | KOBNUT |
| 6. | VG1665799004 | [6] | GASKET | KOB |
| 7. | VG1661896000 | [6] | NUT | KOBRETAINING |
| 9. | VG1660896000 | [12] | PIN | KOBDOWEL |
| 10. | VG1661490000 | [6] | SPRING SEAT | KOBSPRING |
| 11. | VG16657Z9000 | [6] | GASKET | KOB |
| 12. | VG1661999002 | [6] | HYD CONNECTOR | KOB |
| 15. | VG1662096511 | [6] | NOZZLE | KOB(FOR A3) |
| 15. | VG1662096502 | [6] | NOZZLE | KOBASSY (FOR A1) |
| 15. | VG1662096505 | [6] | NOZZLE ASSY (FOR A2) | |
