| 1. |
84822286
|
[1] |
DRAWBAR
|
PLO
, Serial Range: -C667
|
| 1. |
84820089
|
[1] |
DRAWBAR
|
PLO
, Start Serial: D668
|
| 2. |
84320000
|
[1] |
SUPPORTING ARM
|
PLO
|
| 3. |
84025530
|
[2] |
CLAMP
|
PLO
|
| 4. |
80043140
|
[1] |
BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
ZED
Superseded by part number: 43140
|
| 5. |
80140045
|
[1] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 6. |
80100037
|
[4] |
NUT,M10 x 1.5, Class 8
|
ZED
M10 Superseded by part number: 100037
|
| 7. |
84024396
|
[1] |
SUPPORTING ARM
|
PLO
|
| 8. |
84025473
|
[4] |
BOLT,Hex, M16 x 80mm, Cl 12.9
|
PLO
M16x80
|
| 9. |
80333040
|
[12] |
WASHER
|
ZED
Superseded by part number: 333040
|
| 10. |
80333041
|
[8] |
WASHER
|
ZED
Superseded by part number: 333041
|
| 11. |
80394631
|
[4] |
WASHER
|
ZED
16MM Superseded by part number: 394631
|
| 12. |
100020
|
[8] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 13. |
84024970
|
[4] |
BOLT
|
PLO
M16x110
|
| 14. |
86508350
|
[1] |
BOLT,Hex, M20 x 110mm, Cl 10.9
|
PLO
M20x110
|
| 15. |
84025013
|
[1] |
BOLT,Hex, M20 x 140mm, Cl 10.9
|
PLO
M20x140
|
| 16. |
80394632
|
[4] |
WASHER
|
ZED
20MM Superseded by part number: 394632
|
| 17. |
100023
|
[2] |
NUT,M20
|
ZED
Superseded by part number: 9706694
|
| 18. |
84025011
|
[2] |
PLATE
|
PLO
|
| 19. |
84822134
|
[1] |
TUBE,21.50 mm DIA x 700, 270 mm L
|
PLO
RH, Serial Range: -C667 Superseded by part number: 84820187
|
| 19. |
84820187
|
[1] |
TUBE,21.30 mm DIA x 700, 270 mm L
|
PLO
, Start Serial: D668
|
| 20. |
84822135
|
[1] |
TUBE,21.30 mm OD x 700, 270 mm L
|
PLO
LH, Serial Range: -C667 Superseded by part number: 84820186
|
| 20. |
84820186
|
[1] |
TUBE,27.30 mm OD x 700, 270 mm L
|
PLO
, Start Serial: D668 Superseded by part number: 84024967
|
| 21. |
120104
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 22. |
80322358
|
[4] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 23. |
43362
|
[4] |
NUT,M8 x 1.25, Cl 10
|
BHB
|
| 24. |
86511674
|
[2] |
BOLT,Hex, M20 x 120mm, Cl 10.9
|
PLO
M20x120 Superseded by part number: 86639035
|
| 25. |
84320492
|
[1] |
CABLE
|
PLO
|
| 26. |
84320957
|
[1] |
BUSHING
|
PLO
|
| 27. |
86592703
|
[1] |
WASHER,21mm ID x 50mm OD x 6mm Thk
|
ZED
|
| 28. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 29. |
84100999
|
[1] |
SUPPORT
|
PLO
|
| 30. |
84025474
|
[2] |
BOLT,Hex, M16 x 55mm, Cl 12.9
|
PLO
M16x55
|
| 31. |
80392530
|
[6] |
NUT
|
ZED
M16 Superseded by part number: 392530
|
