神钢零件查询(F4GE9484A J600) - ENGINE 504120790 - 87052264 (1/07-12/10) (0.08.1) - CONNECTING ROD (2856312) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
937 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831298 | [4] | CONNECTING ROD | TOR- ASSY |
| . . | 2831298R | [4] | REMAN-CONNECTING ROD | TORF4GE9484A J600 ENGINE 504120790 - 87052264 |
| . . | 2831298C | [1] | CORE-ROD CONNECTING | TORReturn Number |
| 2. | 4892708 | [1] | BUSHING,38.02mm ID x 41.01mm OD x 33.4mm L | TOR |
| 3. | 2831297 | [2] | FLANGE BOLT,Hex, M10 x 1.25 x 52mm, Cl 10.9 | TOR |
| 4. | 8093882 | [4] | BEARING SET | TOR |
| 4. | 8094960 | [4] | BEARING SET,(-0.250) | TOR |
| 4. | 8094961 | [4] | BEARING SET,(-0.500) | TOR |
