纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (0.060[01]) - CYLINDER HEAD DC70 - DC80 - DC100 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
348 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76193242 | [1] | PISTON SWIVEL HEAD | TORSWIVEL HEAD PISTON Superseded by part number: 76193645 |
| 2. | 76192073 | [2] | PLUG | TOR Superseded by part number: 76192228 |
| 3. | 76102466 | [2] | PLUG | HIT Superseded by part number: REFERENCE |
| 4. | 76106568 | [5] | PLUG | LEC |
| 5. | 76191872 | [8] | ROCKER ARM COTTER | TOR Superseded by part number: CASJ900250 |
| 6. | 76192377 | [8] | SPRING | TOR Superseded by part number: J926700 |
| 7. | 3900299 | [8] | CUP | LEC Superseded by part number: 87433959 |
| 8. | 76192074 | [4] | GASKET | TOR Superseded by part number: 76195577, 87433959, 87433962 |
| 9. | 76192370 | [4] | SEAL | TOR Superseded by part number: 76195577, 87433959, 87433962 |
| 10. | 3802355 | [4] | STD INLET VALVE | LSTD ENGINE INLET VALVE Superseded by part number: 76191867 |
| 11. | 3802356 | [4] | STD EXHAUST VALVE | LSTD ENGINE EXHAUST VALVE Superseded by part number: 4895188 |
| 12. | 76192021 | [4] | SCREW | TOR12X1,75X70 Superseded by part number: J920779 |
| 13. | 76192022 | [10] | SPECIAL BOLT | TOR12X1,75X120 Superseded by part number: J920780 |
| 14. | 76192026 | [1] | GASKET | TOR- THICKNESS 0,25 mm Superseded by part number: J283336 |
| 14. | 76192027 | [1] | GASKET | TOR- THICKNESS 0,25 mm Superseded by part number: J283338, 3921397 |
| 14. | 76192025 | [1] | CYLINDER HEAD GASKET | TOR Superseded by part number: 76192277 |
| 15. | 76191921 | [1] | VALVE SEAT | TOR Superseded by part number: J904105 |
| 16. | 76191958 | [1] | VALVE SEAT | TOR Superseded by part number: J906854 |
| 17. | 76191928 | [1] | INTAKE VALVE GUIDE | TOR Superseded by part number: J904408 |
| 18. | 76191929 | [1] | EXHAUST VALVE GUIDE | TOR Superseded by part number: J904409 |
| 19. | 76191955 | [1] | INTAKE VALVE GUIDE | TOR Superseded by part number: J906206 |
