神钢零件查询(F4GE9484A J600) - ENGINE 504120790 - 87052264 (1/07-12/10) (0.24.0) - TURBOCHARGING (2856089 - 2852508) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
305 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899118 | [4] | FLANGE NUT,M8 | TOR Superseded by part number: 500322677 |
| 2. | 4895133 | [1] | GASKET,0.5mm Thk | TOR |
| 4. | 2852510 | [1] | TUBE | TOR Superseded by part number: 504050113 |
| 5. | 2852509 | [1] | MANIFOLD GASKET,0.5mm Thk | TOR Superseded by part number: 504050114 |
| 6. | 4898482 | [3] | BOLT,Flng, M8 x 1.25 x 30mm, Cl 10.9 | TOR |
| 7. | 4899119 | [4] | STUD,M8 x 1.25 x 40 | TOR Superseded by part number: 5801452462 |
