现代零件查询20/25/30/32BC-7 FREE LIFT CYLINDER(TS-MAST, 32BC)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
730 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
3BHN-80200
|
[1] |
CYLINDER ASSY
|
|
| . |
3BHN-80210
|
[1] |
CYLINDER ASSY
|
|
| . |
3BHN-80220
|
[1] |
CYLINDER ASSY
|
|
| . |
3BHN-80230
|
[1] |
CYLINDER ASSY
|
|
| . |
3BHN-80240
|
[1] |
CYLINDER ASSY
|
|
| . |
3BHN-80250
|
[1] |
CYLINDER ASSY
|
|
| . |
3BHN-80260
|
[1] |
CYLINDER ASSY
|
|
| . |
3BHN-80270
|
[1] |
CYLINDER ASSY
|
|
| N . |
3BHN-80280
|
[1] |
CYLINDER ASSY
|
|
| N . |
3BHN-80290
|
[1] |
CYLINDER ASSY
|
|
| 1. |
XKCD-02025
|
[1] |
TUBE ASSY
|
|
| 1. |
XKCD-02030
|
[1] |
TUBE ASSY
|
|
| 1. |
XKCD-02033
|
[1] |
TUBE ASSY
|
|
| 1. |
XKCD-02036
|
[1] |
TUBE ASSY
|
|
| 1. |
XKCD-02039
|
[1] |
TUBE ASSY
|
|
| 1. |
XKCD-02042
|
[1] |
TUBE ASSY
|
|
| 1. |
XKCD-02045
|
[1] |
TUBE ASSY
|
|
| 1. |
XKCD-02048
|
[1] |
TUBE ASSY
|
|
| 1. |
XKCD-02051
|
[1] |
TUBE ASSY
|
|
| 1. |
XKCD-02054
|
[1] |
TUBE ASSY
|
|
| 2. |
XKCD-02068
|
[1] |
ROD
|
|
| 2. |
XKCD-02071
|
[1] |
ROD
|
|
| 2. |
XKCD-02073
|
[1] |
ROD
|
|
| 2. |
XKCD-02075
|
[1] |
ROD
|
|
| 2. |
XKCD-02077
|
[1] |
ROD
|
|
| 2. |
XKCD-02078
|
[1] |
ROD
|
|
| 2. |
XKCD-02080
|
[1] |
ROD
|
|
| 2. |
XKCD-02082
|
[1] |
ROD
|
|
| 2. |
XKCD-02084
|
[1] |
ROD
|
|
| 2. |
XKCD-02086
|
[1] |
ROD
|
|
| 3. |
XKCD-02069
|
[1] |
PISTON
|
|
| K4. |
XKCD-01562
|
[1] |
PISTON SEAL
|
|
| K5. |
XKCD-01668
|
[1] |
RING-WEAR
|
|
| 6. |
XKCD-02024
|
[1] |
VALVE-CHECK
|
|
| 7. |
XKCD-00598
|
[1] |
RING-RETAINING
|
|
| 8. |
XKCD-00843
|
[1] |
SCREW-SET
|
|
| 9. |
XKCD-02028
|
[1] |
ROD COVER
|
|
| K10. |
XKCD-01647
|
[1] |
U-PACKING
|
|
| K11. |
XKCD-00846
|
[1] |
DUST WIPER
|
|
| 12. |
XKCD-00847
|
[1] |
RING-RETAINING
|
|
| K13. |
XKCD-00736
|
[1] |
O-RING
|
|
| K14. |
XKCD-01559
|
[1] |
RING-BACK UP
|
|
| K. |
XKCD-02070
|
[1] |
SEAL KIT
|
|
