凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (14.08[01]) - ROLL BARS GUIDE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
272 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84024121
|
[4] |
SPACER,30mm ID x 54.5mm OD x 24mm L
|
PLO
|
| 2. |
84062595
|
[4] |
BALL BEARING,30mm ID x 55mm OD x 13mm W
|
PLO
|
| 3. |
84062670
|
[2] |
IDLER WHEEL
|
PLO
|
| 4. |
43362
|
[4] |
NUT,M8 x 1.25, Cl 10
|
BHB
|
| 5. |
80300477
|
[4] |
SCREW
|
ZED
M8x16 Superseded by part number: 300477
|
| 6. |
86536801
|
[4] |
SNAP RING,M55, Int
|
NH
|
| 7. |
84062455
|
[2] |
SHIM
|
PLO
|
| 8. |
321204
|
[2] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 9. |
80337563
|
[4] |
SCREW
|
ZED
M12x40 Superseded by part number: 337563
|
| 10. |
80140046
|
[4] |
WASHER
|
ZED
12MM Superseded by part number: 140046
|
| 11. |
84024104
|
[2] |
HINGE
|
PLO
|
| 12. |
337475
|
[4] |
NUT,M12, Cl 10
|
BHB
|
| 13. |
80100037
|
[2] |
NUT,M10 x 1.5, Class 8
|
ZED
Superseded by part number: 100037
|
| 14. |
80120111
|
[8] |
SCREW
|
ZED
M10x30 Superseded by part number: 43140
|
| 15. |
84062459
|
[2] |
SHAFT
|
PLO
Superseded by part number: 84973061
|
