凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (15.02[01]) - TWINE ARM Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
654 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84053928
|
[1] |
PIN
|
PLO
|
| 2. |
84024669
|
[1] |
PIN
|
PLO
|
| 3. |
80381531
|
[2] |
ROLL PIN
|
BEL
10x40 Superseded by part number: 381531
|
| 3. |
80300689
|
[2] |
ROLL PIN
|
NH
6x40
|
| 4. |
80358305
|
[4] |
SLEEVE
|
POL
Superseded by part number: 604085
|
| 5. |
80701272
|
[2] |
GEAR
|
A
Superseded by part number: 86636677
|
| 6. |
80080768
|
[2] |
WOODRUFF KEY
|
PLO
.25x1.00 Superseded by part number: 47471
|
| 7. |
89626568
|
[2] |
NUT
|
PLO
.31 Superseded by part number: 9626568
|
| 8. |
80087230
|
[2] |
SCREW
|
NH
.31x8.8 Superseded by part number: 87230
|
| 9. |
84056289
|
[1] |
ARM
|
PLO
|
| 10. |
84056290
|
[1] |
ARM
|
PLO
|
| 11. |
80378245
|
[3] |
WASHER
|
ZED
12MM Superseded by part number: 378245
|
| 12. |
80130003
|
[3] |
COTTER PIN
|
ZED
3.2x20 Superseded by part number: 130003
|
| 13. |
80100067
|
[1] |
NUT
|
ZED
M8 Superseded by part number: 86528579
|
| 14. |
80378243
|
[1] |
WASHER
|
ZED
8MM Superseded by part number: 378243
|
| 15. |
84024817
|
[1] |
COVER PLATE
|
PLO
|
| 16. |
84062212
|
[1] |
SUPPORT
|
PLO
|
| 17. |
84024806
|
[1] |
SPACER
|
PA
|
| 18. |
84024794
|
[1] |
BUSHING
|
NH
|
| 19. |
83981963
|
[1] |
SNAP RING,M8 x 0.66mm Thk
|
ZED
|
| 20. |
300476
|
[2] |
SET SCREW,Hex Soc, M8 x 12 Cup Pt
|
ZED
Superseded by part number: 84814918
|
| 21. |
84056188
|
[1] |
STOP
|
PLO
LH
|
| 21. |
84056187
|
[1] |
STOP
|
PLO
RH
|
| 22. |
84025077
|
[1] |
STRIP
|
PLO
|
| 23. |
84056287
|
[1] |
TUBE,158 mm Length
|
PLO
|
| 24. |
80120031
|
[5] |
SCREW,M6 x 16mm
|
ZED
M6x16 Superseded by part number: 86512439
|
| 25. |
80322357
|
[5] |
LOCK WASHER,Belleville, M6
|
ZED
6MM Superseded by part number: 322357
|
| 26. |
15896221
|
[5] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 27. |
84053874
|
[2] |
CLAMP
|
PLO
|
