| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
VOE11370180
|
[1] |
Crankshaft
|
|
| 2. |
ZM2290400
|
[5] |
Crankshaft bearing
|
70,00 MM
|
| 2. |
ZM2900539
|
[REQ] |
Crankshaft bearing
|
69,75 mm
|
| 2. |
ZM2290402
|
[REQ] |
Crankshaft bearing
|
69,50 MM
|
| 3. |
VOE20944762
|
[1] |
Thrust Washer
|
2,40 mm
|
| 3. |
VOE20944769
|
[REQ] |
Thrust Washer
|
2,60 mm
|
| 4. |
ZM2908532
|
[1] |
Flywheel
|
|
| 5. |
VOE17471748
|
[1] |
Starter Gear Ri
|
|
| 6. |
ZM2290407
|
[8] |
Screw
|
|
| 7. |
ZM2290408
|
[1] |
Toothed belt wheel
|
|
| 8. |
ZM2904102
|
[1] |
Flange
|
|
| 9. |
VOE11370135
|
[1] |
Deflector
|
|
| 10. |
ZM2290411
|
[1] |
Screw
|
|
| 11. |
ZM2905385
|
[1] |
V-belt pulley
|
|
| 12. |
ZM2908482
|
[8] |
Screw
|
|
| 13. |
ZM2904105
|
[4] |
Connecting rod
|
|
| 14. |
ZM2290416
|
[1] |
Bushing
|
29,06 - 29,10 MM
|
| 14. |
ZM2904108
|
[REQ] |
Bushing
|
29,31 - 29,35 MM
|
| 15. |
ZM2904106
|
[2] |
Screw
|
|
| 16. |
ZM2290415
|
[2] |
Nut
|
|
| 17. |
ZM2290432
|
[4] |
Big end bearing
|
55,00 MM
|
| 17. |
ZM2900542
|
[REQ] |
Big end bearing
|
54,75 mm
|
| 17. |
ZM2900543
|
[REQ] |
Big end bearing
|
54,50 MM
|
| 18. |
ZM2290409
|
[1] |
Toothed belt wheel
|
|
| 19. |
VOE11370230
|
[1] |
Spacer
|
|
| 20. |
VOE11370229
|
[1] |
Deflector
|
|
