凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (15.23[01]) - CHAIN AND ROLLS - C651 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
835 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
-
|
[1] |
, Serial Range: (2-6)
|
|
| 2. |
84821064
|
[1] |
SHAFT
|
PLO
|
| 3. |
84821062
|
[1] |
DRIVEN SPROCKET
|
PLO
|
| 4. |
84821060
|
[1] |
DRIVEN SPROCKET
|
PLO
|
| 5. |
80300477
|
[4] |
SCREW
|
ZED
Superseded by part number: 300477
|
| 6. |
80323190
|
[2] |
KEY
|
ZED
Superseded by part number: 323190
|
| 8. |
84821063
|
[1] |
SHAFT
|
PLO
|
| 9. |
84821061
|
[2] |
DRIVEN SPROCKET
|
PLO
|
| 12. |
84821057
|
[2] |
SUPPORT
|
PLO
|
| 13. |
84821058
|
[4] |
ROLLER
|
PLO
|
| 14. |
80210049
|
[4] |
BALL BEARING
|
ZED
Superseded by part number: 210049
|
| 15. |
80370013
|
[4] |
SNAP RING
|
ZED
Superseded by part number: 370013
|
| 16. |
80370006
|
[8] |
SNAP RING
|
ZED
Superseded by part number: 370006
|
| 17. |
84814912
|
[3] |
BALL BEARING,35 mm ID x 72 mm OD x 51.1 mm
|
ZED
Superseded by part number: 87605590
|
| 18. |
84821113
|
[3] |
BEARING HOUSING
|
PLO
|
| 19. |
86511324
|
[6] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
M12x40 Superseded by part number: 87364
|
| 20. |
80140018
|
[6] |
WASHER
|
ZED
12MM Superseded by part number: 87364
|
| 21. |
321204
|
[3] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 22. |
84820085
|
[2] |
LINK,Chain
|
ZED
|
| 23. |
80393698
|
[2] |
SCREW,M10 x 25mm
|
ZED
M10x25 Superseded by part number: 393698
|
| 24. |
80043139
|
[2] |
BOLT,M10 x 25mm
|
ZED
Superseded by part number: 11106231
|
| 25. |
80140045
|
[2] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 26. |
84821066
|
[1] |
SUPPORT
|
PLO
|
| 27. |
84821068
|
[1] |
PLATE
|
PLO
|
| 28. |
89706687
|
[2] |
SCREW
|
ZED
M12x30 Superseded by part number: 9706687
|
| 29. |
80140046
|
[10] |
WASHER
|
ZED
12MM Superseded by part number: 140046
|
| 30. |
84821093
|
[2] |
CHAIN,60 Links x 50.8mm = 3048mm
|
PLO
(22)
|
| 31. |
84821069
|
[15] |
SUPPORT
|
PLO
|
| 32. |
80120069
|
[60] |
SCREW
|
ZED
M10x50 Superseded by part number: 120069
|
| 33. |
80300388
|
[8] |
SCREW,M12 x 25mm
|
ZED
M12x25 Superseded by part number: 300388
|
| 34. |
80170012
|
[2] |
KEY
|
ZED
Superseded by part number: 170012
|
| 35. |
84818581
|
[1] |
HYDRAULIC MOTOR
|
PLO
|
