纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (0.550[02B]) - ENGINE COOLING SYSTEM DC100 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
260 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76590890 | [1] | PAN | MAC |
| 2. | 76590891 | [1] | CLAMP | MAC |
| 3. | 76590892 | [1] | FLEXIBLE HOSE | TOR Superseded by part number: 70920388 |
| 4. | 76590893 | [2] | CLAMP | MAC Superseded by part number: 12178990 |
| 5. | 76590894 | [1] | SUPPORT | MAC |
| 6. | 76590895 | [2] | WASHER | MAC Superseded by part number: 86639313 |
| 7. | 76590848 | [2] | NUT | MAC- SELF-LOCKING Superseded by part number: 15503611 |
| 8. | 76592892 | [1] | TUBE | MAC |
| 9. | 76593024 | [2] | CLAMP | MAC |
| 10. | 76590774 | [1] | HYD. TUBE | MAC |
| 12. | 76605860 | [2] | COLLAR | MAC |
| 14. | 76605861 | [1] | HOSE | MAC |
| 15. | 76590904 | [1] | WASHER | MAC |
| 16. | 76590905 | [1] | HYD CONNECTOR | MAC |
| 17. | 76590906 | [1] | DRAINCOCK/TAP SUPPLY | TOR |
| 18. | 76590907 | [1] | WASHER | MAC |
| 22. | 76605862 | [1] | HOSE | MAC |
| 23. | 76590902 | [1] | CLAMP | MAC Superseded by part number: 82012730 |
