斗山零件查询INJECTION PUMP DRIVE DX360LCA(S/N:5950~) Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
318 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
130412-00159
|
[1] |
|
|
| 16. |
400602-00738
|
[1] |
|
|
| 17. |
65.90020-0079
|
[3] |
BOLT;HEX ASS'Y M10X35
|
|
| 1A. |
65.11309-0011C
|
[1] |
HOUSING;INJECTION DRIVE
|
|
| 1B. |
06.32092-0308
|
[2] |
BEARING;TAPER ROLLER
|
|
| 1C. |
401106-00350
|
[1] |
|
|
| 1D. |
65.11308-0048
|
[1] |
|
|
| 1D. |
65.11308-0049
|
[1] |
|
|
| 1D. |
65.11308-0050
|
[1] |
|
|
| 1D. |
65.11308-0062
|
[1] |
|
|
| 1E. |
65.91701-0219
|
[1] |
SPACER
|
|
| 1F. |
65.11312-0008
|
[1] |
COVER
|
|
| 1G. |
06.01913-3115
|
[3] |
BOLT ASS`Y M8X25
|
|
| 1H. |
65.11302-0019A
|
[1] |
SHAFT
|
|
| 1I. |
06.29141-0215
|
[1] |
KEY;WOODRUFF
|
|
| 1J. |
65.11301-0026A
|
[1] |
GEAR;INJECTION PUMP DRIVE
|
|
| 1K. |
65.90640-0021
|
[1] |
NUT;HEX. M24X1.5
|
|
