凯斯零件查询(RBX441) - CASE IH ROUND BALER (11/01-8/02) (001) - POWER TAKE OFF, 540 RPM, SHEARBOLT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
1014 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Power Take Off {86604843}
|
| 2. |
86625858
|
[1] |
KIT
|
NH
Superseded by part number: 87552892
|
| 3. |
86625859
|
[1] |
KIT
|
NH
Superseded by part number: 87552892
|
| 7. |
86625852
|
[1] |
RING NUT
|
NH
|
| 8. |
86625851
|
[1] |
RING NUT
|
NH
|
| 10. |
86625856
|
[1] |
PTO SHAFT
|
NH
|
| 11. |
86625857
|
[1] |
PTO SHAFT
|
NH
|
| 12. |
86625876
|
[1] |
HUB
|
NH
|
| 13. |
86625855
|
[1] |
KIT
|
NH
Superseded by part number: 87461438
|
| 14. |
86625850
|
[2] |
U-JOINT SPIDER
|
NH
|
| 15. |
86625844
|
[1] |
BODY
|
NH
|
| 16. |
86625846
|
[1] |
PIN
|
NH
Superseded by part number: 87586150
|
| 17. |
86625848
|
[1] |
YOKE
|
NH
|
| 18. |
86625845
|
[1] |
TUBE,962 mm L
|
NH
|
| 19. |
86625847
|
[1] |
TUBE,967.50 mm L
|
NH
|
| 20. |
86625842
|
[1] |
BEARING ASSY
|
NH
Superseded by part number: 87018246
|
| 24. |
86625854
|
[1] |
RING NUT
|
NH
|
| 25. |
86643178
|
[1] |
BOLT
|
NH
& Nut, M6 x 45
|
| 28. |
86625865
|
[1] |
KIT
|
NH
Tapered
|
| 29. |
86625841
|
[1] |
YOKE
|
NH
|
