神钢零件查询(F4GE9484A J601) - ENGINE - 504103783 - 920019898 (1/13-) (0.32.6) - THERMOSTAT - ENGINE COOLING SYSTEM (504083230-504083237-504033593) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
265 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899091 | [3] | SCREW,Hex Flange Cap, M8 x 1.25 x 40.00mm | BAS |
| 2. | 2853131 | [1] | HOUSING | TOR Superseded by part number: 504079269 |
| 4. | 2853133 | [1] | GASKET,51.5mm ID x 61.5mm OD x 16.5mm Thk | TOR Superseded by part number: 504078856 |
| 7. | 2852473 | [1] | GASKET,53.62mm ID x 59.72mm OD x 4.01mm Thk | TOR Superseded by part number: 504030960 |
