纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (6.712[01E]) - ELECTRIC COMPONENTS - DASHBOARD (DC100 STD. S/N 13111229 & DOWN; LGP S/N 13115068 & DOWN) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
928 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76598464 | [1] | LIGHT SWITCH | MACFRONT WORK LIGHTS |
| 2. | 76598465 | [1] | LIGHT SWITCH | MACREAR WORK LIGHTS |
| 3. | 76598466 | [1] | WINDSHIELD WIPER SWITCH | MACFRONT WINDSHIELD WIPER |
| 4. | 76598469 | [1] | WINDSHIELD WIPER SWITCH | MACREAR WINDSHIELD WIPER |
| 5. | 76598470 | [1] | SWITCH | MACRIPPER ACTIVATION |
| 6. | 76598471 | [1] | COVER | MAC Superseded by part number: 76089573 |
| 7. | 76598472 | [5] | BULB | MAC Superseded by part number: 14143790 |
| 8. | 76598473 | [1] | WARNING LIGHT | MACELECTRONIC CONTROL UNIT |
| 9. | 76598474 | [1] | WARNING LIGHT | MACOIL FILTER |
| 10. | 76598475 | [1] | WARNING LIGHT | MACFAST GEAR |
| 11. | 76598476 | [1] | WARNING LIGHT | MACFUEL LEVEL |
| 12. | 76598477 | [1] | WARNING LIGHT | MACHYDRAULIC OIL TEMP. |
| 13. | 76598478 | [1] | GAUGE | MACFUEL GAGE Superseded by part number: 85803977 |
| 14. | 76609750 | [1] | WARNING LIGHT | MACVOLTMETER |
| 15. | 76598480 | [1] | HOURMETER | MACTACHOMETER |
| 16. | 76605864 | [1] | INSTRUMENT CLUSTER | MACENGINE WATER TEMP,GAGUE |
| 17. | 76598482 | [1] | GAUGE | MACVOLTMETER |
| 18. | 76598483 | [1] | WARNING LIGHT | MACBATTERY |
| 19. | 76598491 | [1] | WARNING LIGHT | MACENGINE OIL PRESSURE |
| 20. | 76598492 | [1] | WARNING LIGHT | MACAIR FILTER |
| 21. | 76598493 | [1] | WARNING LIGHT | MACWATER TEMPERATURE |
| 22. | 76598495 | [1] | WARNING LIGHT | MACPARKING BRAKE |
| 23. | 76593276 | [1] | FUSE BOX | MACCASE |
| 24. | 9804895 | [1] | FUSE,20A, Micro, Yellow | NH |
| 25. | 76592446 | [6] | FUSE | MAC Superseded by part number: 11055090 |
| 26. | 76592447 | [4] | FUSE | MAC Superseded by part number: 11054990 |
| 27. | 76590934 | [2] | NUT | MAC- SELF-LOCKING NUT Superseded by part number: 12574221 |
| 28. | 76590873 | [7] | WASHER | MAC Superseded by part number: 10519404 |
| 29. | 76590872 | [5] | SCREW | MAC Superseded by part number: 120100 |
| 30. | 76593282 | [1] | BUZZER | MAC |
| 31. | 76593283 | [1] | HORN | MAC |
| 32. | 76590847 | [2] | WASHER | MAC Superseded by part number: 10519624 |
| 33. | 76590845 | [1] | SCREW | MAC |
| 34. | 76590848 | [1] | NUT | MAC- SELF-LOCKING Superseded by part number: 15503611 |
| 35. | 76593284 | [3] | NUT | MAC- SELF-LOCKING |
| 36. | 76593285 | [3] | SUPPORT | MAC |
| 37. | 76592454 | [1] | ELECTRO-VALVE | MACELECTRONIC CONTROL UNIT |
| 38. | 76593286 | [1] | PANEL | MAC |
| 39. | 76591021 | [2] | LOCK WASHER | MAC |
| 40. | 76591364 | [2] | SCREW | MAC Superseded by part number: 628-8020 |
| 41. | 76593287 | [1] | HYD CONNECTOR | MAC |
| 42. | 76593288 | [1] | FUSE HOLDER | MAC |
| 43. | 76595730 | [1] | FUSE | MAC |
| 47. | 76593291 | [2] | SCREW | MAC |
| 48. | 76590917 | [2] | LOCK WASHER | MACLOCKWASHER |
| 49. | 76590931 | [2] | WASHER | MAC |
| 50. | 76593292 | [1] | WIRE HARNESS | MACHARNESS |
| 51. | 76593293 | [1] | SUPPORT | MAC |
| 52. | 76593501 | [5] | BULB | MACLAMP Superseded by part number: 14143990 |
| 53. | 76598497 | [1] | DASH PANEL | MAC |
| 54. | 76593274 | [6] | SCREW | MAC Superseded by part number: 10377011 |
| 55. | 76593275 | [6] | WASHER | MAC Superseded by part number: 10519404 |
| 56. | 76593272 | [1] | CIGARETTE LIGHTER | MACCIGARETTE LIGHTER |
| 57. | 76593278 | [1] | IGNITION SWITCH | MACBLOCK; Uses 73171248 Key |
| . . | 73171248 | [1] | WRENCH | BERKEY, LOCK Superseded by part number: 85804675 |
| 58. | 76598498 | [1] | DASH PANEL | MACWITH WIRING HARNESS WHICH IS NOT SERVICED SEPARATELY |
| 59. | 76598500 | [1] | REPAIR KIT | MACKit, Electrical Connectors |
| 60. | 76592448 | [1] | SWITCH | MAC |
