| 1. |
700039
|
[2] |
ANGLE
|
NH
Superseded by part number: 9820171
|
| . . |
412327
|
[4] |
CARRIAGE BOLT,Short Sq Nk, M6 x 1 x 40mm, Full Thd, Cl 8.8
|
NH
|
| . . |
832-46406
|
[4] |
NUT,M6 x 1, Cl 8
|
CAS
Superseded by part number: 353308
|
| . . |
495-21031
|
[4] |
WASHER,1/4"
|
CAS
Superseded by part number: 80701, 72187262
|
| 3. |
86628550
|
[4] |
SPRING
|
NH
|
| 4. |
86619047
|
[1] |
SHIELD
|
NH
|
| . . |
412093
|
[2] |
SELF-TAP SCREW
|
NH
M6 x 1 x 12
|
| 5. |
9617079
|
[1] |
COVER PLATE
|
NH
Flat
|
| . . |
811-8020
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| . . |
825-5148
|
[2] |
SERRATED NUT,M8, Flg Ser
|
CAS
Superseded by part number: 86505868
|
| 6. |
9617359
|
[1] |
BAR
|
NH
|
| . . |
140109
|
[1] |
WASHER,31mm ID x 40mm OD x 2mm Thk
|
NH
|
| . . |
733-4040
|
[1] |
COTTER PIN,M4 x 40
|
CAS
Superseded by part number: 80708
|
| . . |
811-10020
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86512422
|
| . . |
825-51410
|
[2] |
FLANGE NUT,M10, Flg Ser
|
CAS
Superseded by part number: 43435
|
| . . |
25939
|
[4] |
WASHER,13.5mm ID x 44.5mm OD x 5mm Thk
|
NH
Special
|
| . . |
825-51412
|
[1] |
FLANGE NUT,M12, Flg Ser
|
CAS
Superseded by part number: 43436
|
| . . |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Lube Fitting, Straight, 1/4"-28
|
| 7. |
9608242
|
[1] |
DRIVING SPROCKET
|
NH
46T
|
| . . |
614-10020
|
[2] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| . . |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| . . |
825-1410
|
[2] |
NUT,M10, Cl 8
|
CAS
Superseded by part number: 100016
|
| 8. |
86635254
|
[1] |
LEVER
|
NH
Twine
|
| . . |
420434
|
[2] |
BUSHING,30mm ID x 34mm OD x 20mm L
|
NH
|
| 9. |
617945
|
[1] |
KNIFE SECTION
|
NH
Twine Cutting
|
| . . |
811-6016
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 16mm, Cl 8.8
|
CAS
Superseded by part number: 86512439
|
| 10. |
86635368
|
[1] |
SUPPORT
|
NH
Knife
|
| . . |
244379
|
[1] |
WASHER,13.49mm ID x 19.05mm OD x 2.67mm Thk
|
NH
|
| . . |
394818
|
[1] |
COTTER PIN,M5 x 25
|
NH
M5 x 20
|
| . . |
219-93
|
[1] |
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
|
CAS
Superseded by part number: 87415
|
| 11. |
86635255
|
[1] |
SUPPORT
|
NH
Knife
|
| . . |
378245
|
[3] |
WASHER,13mm ID x 28.5mm OD x 2.7mm Thk
|
NH
|
| . . |
905-8016
|
[3] |
BOLT,Hex Flg, M8 x 16mm
|
CAS
Superseded by part number: 86511478
|
| 12. |
86635215
|
[1] |
YOKE
|
NH
|
| . . |
832-46410
|
[1] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| . . |
495-21044
|
[4] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| . . |
814-10040
|
[1] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 120112
|
| 13. |
838-5426
|
[1] |
LOCK PIN,M4 x 26, Slotted
|
CAS
Superseded by part number: 190003909597
|
| 14. |
28114
|
[6] |
U-BOLT
|
NH
#10-24 x 1-15/16"
|
| . . |
225-14110
|
[12] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| . . |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 15. |
86543545
|
[6] |
GUIDE
|
NH
Twine, Cast Iron
|
| 16. |
86635014
|
[3] |
SPRING
|
NH
|
| . . |
495-21038
|
[2] |
WASHER,5/16"
|
CAS
Superseded by part number: 80664, 72187263
|
| . . |
432-812
|
[1] |
COTTER PIN,3/4" OAL x 1/8" W
|
CAS
Superseded by part number: 80756
|
| 17. |
86635386
|
[1] |
ROD
|
NH
|
| 18. |
9617078
|
[1] |
STOP
|
NH
|
| . . |
811-10030
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 19. |
84377502
|
[1] |
ELECTRIC MOTOR
|
NH
|
| . . |
795230
|
[1] |
HYD CONNECTOR
|
NH
Superseded by part number: 225161C1
|
| . . |
900363
|
[2] |
TERMINAL
|
NH
E 18 Superseded by part number: 87697947
|
| . . |
410448
|
[1] |
ELECTRIC MOTOR
|
NH
|
| . . |
410448R
|
[1] |
REMAN-ELECTRIC MOTOR
|
NH
RBX441
|
| . . |
410448C
|
[1] |
CORE-ELECTRIC MOTOR
|
NH
Return Number
|
| . . |
900367
|
[1] |
TERMINAL
|
NH
E18 Superseded by part number: 84068583
|
| . . |
515-23143
|
[1] |
CLAMP,9/16", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 257492, 72187280
|
| . . |
495-21019
|
[1] |
WASHER,#8
|
CAS
Superseded by part number: 280299, 72187261
|
| . . |
614-4016
|
[1] |
BOLT,Hex, M4 x 0.7 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 412064
|
| 20. |
9608237
|
[1] |
CHANNEL
|
NH
|
| . . |
614-6020
|
[3] |
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120100
|
| 21. |
86635210
|
[1] |
DRIVING SPROCKET
|
NH
|
| 22. |
9614082
|
[1] |
CHAIN
|
NH
RC41, 59 Pitches Superseded by part number: 475879R91X
|
| 23. |
9608238
|
[1] |
DRIVING SPROCKET
|
NH
Double
|
| . . |
219-87
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| . . |
814-12100
|
[1] |
BOLT,Hex, M12 x 1.75 x 100mm, Cl 8.8
|
IH
Superseded by part number: 374887
|
| . . |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| . . |
382974
|
[2] |
BUSHING,20.05mm ID x 23mm OD x 15mm L
|
NH
|
| 24. |
86635140
|
[1] |
SPACER
|
NH
|
| 25. |
9616726
|
[1] |
CHAIN
|
NH
RC41, 96 Pitches Superseded by part number: 475879R91X
|
| 26. |
9619104
|
[1] |
BAND
|
NH
|
| 27. |
623796
|
[1] |
ROD
|
NH
|
| . . |
425-105
|
[2] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
