| 1. |
858911
|
[1] |
CONTROL
|
NH
Box, Electric Twine Wrap
|
| 2. |
237980
|
[1] |
WIRE CLAMP,11.11mm, Coat, 7.14mm Bolt Hole, P Type
|
NH
7/16" x 1/4"
|
| 3. |
100381
|
[1] |
ELEC CONNECTOR
|
NH
|
| 4. |
136224
|
[1] |
PLUG
|
NH
Electrical
|
| 5. |
PL
|
[1] |
PROCURE LOCALLY
|
BAS
Wire
|
| 6. |
701592
|
[1] |
BUZZER
|
NH
|
| 7. |
285444
|
[1] |
COVER
|
NH
|
| 8. |
847590
|
[1] |
BRACKET
|
NH
Socket
|
| 9. |
9801636
|
[1] |
BRACKET
|
NH
Mounting
|
| 10. |
254398
|
[2] |
WIRE HARNESS
|
NH
|
| 11. |
86516721
|
[1] |
SWITCH
|
NH
Twine Wrapper Control
|
| 12. |
602997
|
[2] |
TOGGLE SWITCH
|
NH
|
| 15. |
768120
|
[1] |
CIRCUIT BREAKER,20A
|
NH
|
| 16. |
858904
|
[1] |
WIRE HARNESS
|
NH
|
| 18. |
860003
|
[1] |
WIRE HARNESS
|
NH
Battery to Switch &, Serial Range: Ground-Light
|
| 19. |
46432
|
[2] |
TERMINAL CONNECTOR,12 - 10 SAE
|
NH
Ring, #10
|
| 20. |
768125
|
[1] |
FUSE
|
NH
|
| 21. |
784122
|
[2] |
PLUG
|
NH
Button, 1-1/2"
|
| 22. |
858841
|
[1] |
BOX
|
NH
|
| 23. |
767915
|
[1] |
SWITCH
|
NH
On/Off Power
|
| 24. |
718450
|
[1] |
WIRE
|
NH
|
| 25. |
86613396
|
[1] |
TAIL LAMP
|
NH
Full Bale Alarm Lamp
|
| 26. |
787868
|
[1] |
BRACKET
|
NH
|
| 27. |
636665
|
[1] |
LOCK WASHER,43.18mm ID x 52.68mm OD x 1.57mm Thk
|
NH
Superseded by part number: 84607513
|
| 28. |
636666
|
[1] |
NUT,1 11/16"-18
|
NH
UNEF-2B, 178" Thick, 1.875 Wide Superseded by part number: 459329C1
|
| 29. |
767456
|
[1] |
PLUG
|
NH
Dust Cover Superseded by part number: 87716289
|
| 30. |
617887
|
[1] |
HOOK
|
NH
S
|
| 31. |
275-5478
|
[4] |
SELF-TAP SCREW,Hex Hd, 1/4" x 1/2"
|
CAS
Superseded by part number: 87667
|
| 32. |
84461
|
[2] |
SCREW,Slotted Truss Hd, #10 - 24 x 5/8"
|
NH
|
| 33. |
80684
|
[2] |
LOCK WASHER,4.9mm ID x 8.48mm OD x 1.19mm Thk
|
NH
|
| 34. |
225-14110
|
[2] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 35. |
495-31022
|
[1] |
WASHER,#10
|
CAS
Superseded by part number: 88612
|
| 36. |
433-412
|
[1] |
CARRIAGE BOLT,Sq Nk, 1/4" - 20 x 3/4", Gr 5
|
CAS
Superseded by part number: 88832
|
| 37. |
231-5144
|
[1] |
SERRATED NUT,Flg, USR, 1/4"-20
|
CAS
Superseded by part number: 523282, 72187066
|
| 38. |
81743
|
[1] |
SCREW,Slotted Truss Hd, #8 - 32 x 1/2"
|
NH
|
| 39. |
492-11008
|
[1] |
LOCK WASHER,#8
|
CAS
Superseded by part number: 87812
|
| 41. |
434-516
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1", Gr 5
|
CAS
Superseded by part number: 88992
|
| 42. |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 43. |
9635082
|
[2] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 44. |
280327
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5, Full Thd
|
NH
|
| 45. |
84821
|
[2] |
SCREW,Truss HD, #10 - 24 x 1/2"
|
NH
|
| 46. |
795644
|
[1] |
ELEC CONNECTOR
|
NH
|
| 47. |
495-21038
|
[4] |
WASHER,5/16"
|
CAS
Superseded by part number: 80664, 72187263
|
| 48. |
145458
|
[2] |
SERRATED NUT,SERRATED NUT 5/16"-18 GR 5 ZND
|
NH
|
| 49. |
86625070
|
[2] |
NUT,Keps, w/LW,#10-32
|
IMO
Superseded by part number: 280942
|
| 51. |
87032435
|
[1] |
LENS
|
PA
Red
|
