凯斯零件查询(RBX442) - CASE IH ROUND BALER (9/02-7/05) (14.70) - ROLL SCRAPER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
237 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86623055
|
[1] |
SUPPORT
|
NH
|
| 2. |
9845575
|
[1] |
SCRAPER BLADE
|
NH
|
| 3. |
322358
|
[9] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 4. |
825-5148
|
[9] |
SERRATED NUT,M8, Flg Ser
|
CAS
Superseded by part number: 86505868
|
| 5. |
614-8020
|
[8] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| 6. |
905-8016
|
[4] |
BOLT,Hex Flg, M8 x 16mm
|
CAS
Superseded by part number: 86511478
|
