纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (9.850[01]) - ACOUSTICAL TREATMENT DC70 - DC80 - DC100 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
287 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76598462 | [1] | SHIELD | MACSUPPORT |
| 2. | 76595960 | [1] | RUBBER SEAL | MACCHANNEL |
| 3. | 76598239 | [1] | LOCK WASHER | MACDEADENING Superseded by part number: 76605521 |
| 4. | 76610041 | [1] | SHIELD | MACCHANNEL |
| 5. | 76610050 | [1] | SCREW | MACDEADENING Superseded by part number: 190003800887 |
| 6. | 76590724 | [1] | WASHER | MACDEADENING Superseded by part number: |
| 7. | 76610380 | [4] | SHIELD | MACCLAMP |
| 8. | 76593277 | [2] | PLUG | MACPLUG |
| 9. | 76591411 | [1] | WASHER | MACPLUG |
| 10. | 76591395 | [2] | NUT | MACPLUG |
| 11. | 76591396 | [1] | SCREW | MACPLUG |
| 12. | 76590946 | [8] | SCREW | LECSCREW |
| 13. | 76590716 | [8] | WASHER | MACWASHER |
| 14. | 76590721 | [8] | LOCK WASHER | MACLOCKWASHER |
| 15. | 76590954 | [8] | NUT | MACNUT Superseded by part number: 86500689 |
| 16. | 76610047 | [1] | SCREW | MACBELT Superseded by part number: 2976844 |
| 17. | 76610046 | [41] | WASHER | MACPULLEY |
| 18. | 76591401 | [1] | WASHER | MACDEADENING |
| 19. | 76610051 | [1] | NUT | MACPANEL Superseded by part number: 86639243 |
| 20. | 47323030 | [1] | FIN | CMISOUNDPROOF PANEL |
| 21. | 47323031 | [3] | PANEL | CMIDEADENING |
| 22. | 76590713 | [4] | WASHER | MACWASHER Superseded by part number: 14496621 |
| 23. | 76590845 | [2] | SCREW | MACSCREW |
| 24. | 76590847 | [4] | WASHER | MACWASHER Superseded by part number: 10519624 |
| 25. | 47323032 | [2] | NUT | CMINUT |
| 31. | 47323033 | [1] | REAR VIEW MIRROR | CMIREAR VIEW MIRROR |
| 32. | 47323034 | [1] | SUPPORT | CMISUPPORT |
| 33. | 10520021 | [1] | WASHER,12.2mm ID x 22mm OD x 3mm Thk | BHB |
| 34. | 76590727 | [1] | WASHER | MACWASHER Superseded by part number: 412123 |
| 35. | 76590733 | [1] | SCREW | MACSCREW Superseded by part number: 11112424 |
| 36. | 47323035 | [1] | COVER | CMICOVER |
