现代零件查询20/25BR-7 CHARGER(48V, 280~365AH)EPC Hyundai _现代Hyundai_工程机械

现代零件查询20/25BR-7 CHARGER(48V, 280~365AH)EPC Hyundai

广数供应链运营团队, 14 02月, 2025，浏览： 378 次

Pos.	Part No	Qty	Parts name	Comments
.	21FP-51011	[1]	CHARGER-3P 220/380V	20BR
.	21FP-51012	[1]	CHARGER-3P 220/380V	20BR
.	21FP-51011	[1]	CHARGER-3P 220/380V	25BR
.	21FP-51012	[1]	CHARGER-3P 220/380V	25BR
.	21FP-51021	[1]	CHARGER-3P 410V	20BR
.	21FP-51022	[1]	CHARGER-3P 410V	20BR
.	21FP-51021	[1]	CHARGER-3P 410V	25BR
.	21FP-51022	[1]	CHARGER-3P 410V	25BR
.	21FP-51031	[1]	CHARGER-3P 440V	20BR
.	21FP-51032	[1]	CHARGER-3P 440V	20BR
.	21FP-51031	[1]	CHARGER-3P 440V	25BR
.	21FP-51032	[1]	CHARGER-3P 440V	25BR
.	21FP-51041	[1]	CHARGER-1P 220V	20BR
.	21FP-51042	[1]	CHARGER-1P 220V	20BR
.	21FP-51041	[1]	CHARGER-1P 220V	25BR
.	21FP-51042	[1]	CHARGER-1P 220V	25BR
1.	B11820250	[1]	FAN
2.	XKCS-00056	[1]	AC OVER LOAD	3P
3.	XKCS-00002	[1]	RESISTOR AS-RD
4.	21FH-89020	[1]	TRANS-AUX
5.	B52820180	[1]	SWITCH-MAGNET	3P
6.	B11820260	[3]	MODULE-SCR	3P
6.	21FY-59020	[2]	MODULE-SCR	1P
6.	21FH-79720	[1]	SSR	1P
7.	XKCS-00003	[1]	BOARD AS-MONITOR
8.	XKCS-00015	[1]	CABLE AS-DC OUTPUT	WCT 25SQ
9.	21FH-79740	[1]	RESISTOR AS-DR	3P 220/380
9.	21FH-79750	[1]	RESISTOR AS-DR	3P 410/440
10.	XKCS-00016	[1]	MAIN TRANSFORMER-AS	3P 220/380
10.	XKCS-00017	[1]	MAIN TRANSFORMER-AS	1P 220
10.	XKCS-00018	[1]	MAIN TRANSFORMER	3P 410
10.	XKCS-00019	[1]	MAIN TRANSFORMER	3P 440
11.	XKCS-00009	[1]	CABLE AS-AC INPUT
12.	XKCS-00020	[1]	BOARD AS-MAIN	3P
12.	XKCS-00021	[1]	BOARD AS-MAIN	1P
13.	XKCS-00022	[1]	CHOKE FILTER
14.	XKCS-00013	[1]	FUSE
