纽荷兰零件查询(DC150.B) - CRAWLER DOZER TIER 2 (3/03-) (1.200[02]) - UNIT TORQUE CONVERTER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
492 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76073530 | [2] | SHAFT | LEC |
| 2. | 79010927 | [2] | GEAR | LEC |
| 3. | 11067476 | [2] | SNAP RING,M26, Ext | LEC |
| 4. | 11061076 | [4] | SNAP RING,M62, Int | ZED Superseded by part number: 370012 |
| 5. | 14460581 | [2] | O-RING,67.94mm ID x 2.62" Width | BAS Superseded by part number: 17285081 |
| 6. | 76073531 | [2] | SPACER | LEC27,9X1,5 |
| 7. | 76073529 | [2] | SPACER,30.1mm ID x 35mm OD x 28mm L | LEC- PUMP |
| 8. | 20685450 | [4] | BALL BEARING,30 mm ID x 62 mm OD x 16 mm | TTF30X62X16 Superseded by part number: 75224976, 210064, 700803262 |
| 9. | 14458581 | [2] | O-RING,36.17mm ID x 2.62" Width | LEC |
| 10. | 4526900 | [2] | SNAP RING | BRE |
| 11. | 4526899 | [2] | COUPLING RING | BRE |
| 12. | 591794 | [2] | CHANNEL | LEC |
