神钢零件查询(F4GE9484A J613) - ENGINE 5801920069 - 47681264 (1/14-12/14) (10.105.AG) - PISTON & RINGS KIT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
450 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2854603 | [4] | PISTON RING | BHBAlternative parts |
| 1. | 2830158 | [4] | PISTON RING,95.4mm ID x 104mm OD x 2.39mm Thk | TORAlternative parts |
| 1. | 2852037 | [4] | SEAL,95.3mm ID x 104mm OD x 4mm Thk | TORAlternative parts Superseded by part number: 98486083 |
| 2. | 4892712 | [4] | PISTON PIN,38mm OD x 82mm L | TOR |
| 3. | 2855531 | [4] | PISTON | TOR |
| 4. | 2854030 | [8] | SNAP RING,M40.8 OD | TOR Superseded by part number: 504093651 |
