| 1. |
517645R11
|
[6] |
COLLAR
|
IH
Locking, Includes: Set Screw Superseded by part number: 47577188
|
| 2. |
86620026
|
[16] |
FLANGED BEARING
|
NH
|
| 3. |
571588R92
|
[10] |
BALL BEARING,1.3755" ID x 72 mm OD x 1"
|
IH
Superseded by part number: 47066
|
| 4. |
614-10030
|
[16] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43140
|
| 5. |
8050825
|
[2] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
Superseded by part number: F82059
|
| 6. |
9608076
|
[1] |
BEARING ASSY,82.6 mm ID x 138 mm OD x 24 mm
|
NH
Includes: Ref. 7
|
| 7. |
96328C1
|
[1] |
BALL BEARING,40mm ID x 80mm OD x 22mm W
|
CAS
|
| 8. |
140194
|
[1] |
WASHER,41mm ID x 48 mm OD x 1mm Tk
|
NH
M40
|
| 9. |
838-5526
|
[3] |
LOCK PIN,M5 x 26, Slotted
|
CAS
Superseded by part number: 82848074, 130045
|
| 10. |
9823371
|
[1] |
SHAFT
|
NH
Long, Includes: (1) Ref. 9 Superseded by part number: 87023402
|
| 11. |
9608084
|
[1] |
WASHER
|
NH
Radiused Superseded by part number: 86636675
|
| 12. |
143360
|
[2] |
CHAIN
|
NH
Superseded by part number: 136355
|
| 13. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 14. |
86635388
|
[1] |
SUPPORT
|
NH
Roller
|
| 15. |
86521602
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87023400
|
| 16. |
9841725
|
[2] |
O-RING,0.21" Thk x 1.85" ID, -328, 40 Duro
|
NH
M47.00 ID x 5.3
|
| 17. |
86635219
|
[1] |
COVER
|
NH
|
| 18. |
86592924
|
[1] |
ROLLER
|
NH
Drive Superseded by part number: 87015062
|
| 19. |
9842286
|
[1] |
ROLLER
|
NH
Backwrap, Includes: Bearings & Roller Superseded by part number: 84600572
|
| 20. |
353125
|
[1] |
BALL BEARING,45mm ID x 85mm OD x 19mm W
|
NH
|
| 21. |
86635217
|
[1] |
SUPPORT
|
NH
|
| 22. |
9823372
|
[1] |
SHAFT,1135mm L
|
NH
Short, Includes: Ref. 9
|
| 23. |
9842288
|
[1] |
ROLLER,88.9mm OD x 1142mm L
|
NH
Follower, Includes Bearings & Roller Superseded by part number: 84356720
|
| 24. |
86635335
|
[1] |
ROLLER
|
NH
Pivot
|
| 25. |
86635330
|
[6] |
COVER
|
NH
Roller End
|
| 26. |
626286
|
[1] |
SNAP RING
|
NH
Ext, 1.50"
|
| 27. |
9609939
|
[1] |
SUPPORT
|
NH
|
| 28. |
140045
|
[18] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 29. |
614-12030
|
[2] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 9706687
|
| 30. |
9805640
|
[2] |
SHIELD,38.3mm ID x 74.5mm OD x 3.5mm Thk
|
NH
Seal
|
| 31. |
43167
|
[1] |
BOLT,Hex, M16 x 30mm, Cl 8.8, Full Thd
|
NH
|
| 32. |
140048
|
[1] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 33. |
495-21069
|
[1] |
WASHER,5/8"
|
CAS
Superseded by part number: 80299
|
| 34. |
9800957
|
[9] |
WASHER,35.81mm ID x 50.8mm OD x 1.52mm Thk
|
NH
|
| 35. |
811-10030
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 36. |
825-51410
|
[6] |
FLANGE NUT,M10, Flg Ser
|
CAS
Superseded by part number: 43435
|
| 37. |
9609940
|
[2] |
ANGLE
|
NH
|
| 38. |
814-10040
|
[2] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 120112
|
| 39. |
213404
|
[4] |
SPACER,10.3mm ID x 38.1mm OD x 5.2mm OAL
|
NH
3/16" x 13/32" ID x 1-1/2" OD
|
| 40. |
9608110
|
[1] |
HOUSING
|
NH
|
| 41. |
825-1410
|
[4] |
NUT,M10, Cl 8
|
CAS
Superseded by part number: 100016
|
| 42. |
832-46410
|
[4] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 43. |
614-10020
|
[4] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| 45. |
9805638
|
[2] |
SUPPORT
|
NH
|
| 46. |
9822830
|
[1] |
SHIELD
|
NH
LH
|
| 47. |
9822833
|
[1] |
SHIELD
|
NH
RH
|
| 48. |
86635369
|
[1] |
ROLLER
|
NH
Top
|
| 49. |
322357
|
[6] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 50. |
413-410
|
[4] |
BOLT,Hex, 1/4" - 20 x 5/8", Gr 5
|
CAS
Superseded by part number: 280641
|
| 51. |
614-8030
|
[2] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43128
|
| 52. |
495-21038
|
[2] |
WASHER,5/16"
|
CAS
Superseded by part number: 80664, 72187263
|
| 53. |
832-46408
|
[2] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
| 54. |
394629
|
[6] |
WASHER,10.5mm ID x 24mm OD x 3mm Thk
|
ZED
|
| 55. |
627-10030
|
[6] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd
|
CAS
Superseded by part number: 9515003
|
