凯斯零件查询(RBX443) - CASE IH ROUND BALER (9/05-12/06) (18.11) - LH TIRE & WHEEL KIT, STANDARD PICKUP Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
809 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87016425
|
[1] |
DIA KIT, HARVESTER
|
PA
LH Pickup Tire & Wheel, Includes: Installation Instructions
|
| 2. |
86634544
|
[2] |
SEALING RING COLLAR
|
NH
|
| 3. |
86616347
|
[2] |
WHEEL ASSY
|
NH
Superseded by part number: 200734, 136378, 86616348, 132710, 132709, 25447, 136376
|
| 4. |
86616348
|
[2] |
WHEEL
|
NH
|
| 5. |
136376
|
[2] |
SEAL,31.75mm ID x 50.42mm OD x 6.75mm Thk
|
NH
Oil
|
| 6. |
132709
|
[4] |
BEARING CUP,50.29mm OD x 10.67mm W
|
NH
Tapered Roller
|
| 7. |
132710
|
[4] |
BEARING CONE,25.4mm ID x 14.73mm W
|
NH
Tapered Roller
|
| 8. |
26130
|
[2] |
WASHER,26mm ID x 35mm OD x 1.7mm Thk
|
NH
Special, .060" Thk
|
| 9. |
603373
|
[2] |
JAM NUT,Slotted, 1" - 14, Gr 2
|
NH
Jam, G2, 1"-14 Superseded by part number: 143183
|
| 10. |
87398
|
[2] |
COTTER PIN,3/16" OD x 1-1/4" OAL
|
NH
|
| 11. |
200734
|
[2] |
HUB CAP
|
NH
|
| 12. |
25447
|
[2] |
TIRE TUBE
|
NH
Inner, 4.00 - 8
|
| 13. |
136378
|
[2] |
TYRE/TIRE
|
NH
4.80/4.00 x 8, 4 Ply, Tubeless
|
| 14. |
847876
|
[2] |
SUPPORT
|
NH
Bracket
|
| 15. |
811-12040
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 328754
|
| 16. |
614-12040
|
[1] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 17. |
825-1412
|
[2] |
NUT,M12, Cl 8
|
CAS
Superseded by part number: 9706685
|
| 18. |
80679
|
[2] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
