凯斯零件查询(RBX451) - CASE IH ROUND BALER (12/01-10/02) (052) - WIDE PICKUP, TIRES & WHEELS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
594 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
855698
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87655955
|
| 2. |
86634544
|
[2] |
SEALING RING COLLAR
|
NH
|
| 3. |
136376
|
[2] |
SEAL,31.75mm ID x 50.42mm OD x 6.75mm Thk
|
NH
|
| 4. |
D29266
|
[4] |
ROLLER BEARING,1" ID x 0.58"
|
CAS
Superseded by part number: 132710
|
| 5. |
572564R1
|
[4] |
BEARING CUP
|
IH
Superseded by part number: 132709
|
| 6. |
86616348
|
[2] |
WHEEL
|
NH
|
| 7. |
26301
|
[2] |
WASHER
|
NH
1-1/2" OD
|
| 8. |
603373
|
[2] |
JAM NUT,Slotted, 1" - 14, Gr 2
|
NH
Jam, G2, 1"-14 Superseded by part number: 143183
|
| 9. |
200734
|
[2] |
HUB CAP
|
NH
|
| 10. |
86620084
|
[2] |
TUBE,16 mm L
|
NH
16 x 6.5-8
|
| 11. |
PL
|
[2] |
PROCURE LOCALLY
|
BAS
16 x 6.5 - 8, 4 Ply
|
| 12. |
432-1220
|
[2] |
COTTER PIN,3/16" x 1 1/4"
|
CAS
Superseded by part number: 87398
|
| 13. |
425-108
|
[4] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 14. |
492-11056
|
[4] |
LOCK WASHER,9/16"
|
CAS
Superseded by part number: 80280248
|
| 15. |
854719
|
[2] |
CLIP
|
NH
Spring
|
| 16. |
433-828
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
Superseded by part number: 88530
|
