神钢零件查询(F4GE9484C J601) - ENGINE 504203229 - 84513501 (1/14-) (10.103.03) - CRANKCASE COVERS (2855177) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
415 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899026 | [2] | DOWEL,M18 x 10 | TOR |
| 2. | 4899109 | [3] | SCREW,Hex, M10 x 1.5 x 80 | BAS |
| 2. | 4892915 | [7] | FLANGE BOLT,Hex, M10 x 1.5 x 40mm | TOR |
| 2. | 4899076 | [5] | SCREW,Hex Flg, M12 x 1.75 x 80 | TOR |
| 2. | 4899074 | [2] | SCREW,Hex Flg, M12 x 1.75 x 120 | TOR |
| 2. | 4899143 | [1] | SCREW,Hex Flg, M10 x 1.5 x 140 | TOR |
| 2. | 2852865 | [2] | FLANGE BOLT,Hex, Shldr, Lkg, M10 x 33mm | TOR Superseded by part number: 504080094 |
| 3. | 2854075 | [1] | O-RING,0.103" Thk x 2.987" ID, -151 | TOR |
| 4. | 4895378 | [2] | BUTTON PLUG,M29.2 | TOR |
| 5. | 4895379 | [2] | O-RING,21.82mm ID x 3.53mm Width | TOR Superseded by part number: 17288480 |
| 6. | 2854073 | [1] | COVER | TORASSY Superseded by part number: 504115364 |
| 6A. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 7. | 4899020 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16673635 |
| 8. | 4890833 | [1] | OIL SEAL,M130 x 155 x 12.5/16 | TOR Superseded by part number: |
| 10. | 4895155 | [1] | COVER | TOR |
| 11. | 4899068 | [2] | BOLT,Flng, M8 x 1.25 x 16mm | BAS |
| 12. | 4893036 | [1] | PIPE PLUG,3/4"-14 NPTF | TOR Superseded by part number: 2854866 |
