神钢零件查询(F4GE9484C J601) - ENGINE 504203229 - 84513501 (1/14-) (10.402.01[01]) - PIPING - ENGINE COOLING SYSTEM (2852149 - 2852144) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
143 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899109 | [3] | SCREW,Hex, M10 x 1.5 x 80 | BAS |
| 2. | 2854072 | [1] | SEALING RING,Square, 5.16mm Thk x 50.17mm ID | TOR Superseded by part number: 504062710 |
| 3A. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 5. | 4895625 | [1] | O-RING,13.3mm ID x 2.2mm Width | TOR Superseded by part number: 17281681 |
| 6. | 4895623 | [1] | HEX SOCKET PLUG,M16 x 1.5 | TORASSY |
| 6A. | NSS | [1] | NOT SOLD SEPARAT | CON |
