凯斯零件查询(RBX451) - CASE IH ROUND BALER (12/01-10/02) (053) - AUXILIARY TWINE BOX Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
1006 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86618689
|
[1] |
KIT
|
NH
Auxiliary Twine Box, Includes: Ref. 2 - 29 & Instructions
|
| 2. |
811-8020
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 3. |
825-5148
|
[4] |
SERRATED NUT,M8, Flg Ser
|
CAS
Superseded by part number: 86505868
|
| 4. |
86637282
|
[2] |
ANGLE
|
NH
|
| 5. |
832-46406
|
[4] |
NUT,M6 x 1, Cl 8
|
CAS
Superseded by part number: 353308
|
| 6. |
495-21031
|
[4] |
WASHER,1/4"
|
CAS
Superseded by part number: 80701, 72187262
|
| 7. |
412327
|
[4] |
CARRIAGE BOLT,Short Sq Nk, M6 x 1 x 40mm, Full Thd, Cl 8.8
|
NH
|
| 8. |
29840
|
[2] |
SPRING,Compression, 11.91mm OD x 25.4mm L
|
NH
|
| 9. |
86628314
|
[2] |
BRACKET
|
NH
Includes: Ref. 29
|
| 10. |
825-51410
|
[2] |
FLANGE NUT,M10, Flg Ser
|
CAS
Superseded by part number: 43435
|
| 11. |
614-10020
|
[2] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| 12. |
9623638
|
[1] |
ROPE
|
NH
Wire, 54-3/4" Long Superseded by part number: 9828314
|
| 13. |
86631041
|
[4] |
PLATE
|
NH
|
| 16. |
689986
|
[2] |
ANGLE
|
NH
Bracket
|
| 17. |
495-21044
|
[6] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 20. |
696365
|
[1] |
SPACER
|
NH
|
| 21. |
614-8030
|
[1] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43128
|
| 22. |
832-46408
|
[1] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
| 23. |
689987
|
[1] |
ANGLE
|
NH
|
| 24. |
9820171
|
[1] |
BRACKET
|
NH
|
| 25. |
510932
|
[1] |
PULLEY,50.01mm OD
|
NH
|
| 26. |
86637283
|
[2] |
GUIDE
|
NH
Twine
|
| 27. |
86631040
|
[2] |
TWINE BOX
|
NH
Twine Box
|
| 28. |
86631042
|
[4] |
PLATE
|
NH
2-3/4" x 1-1/2"
|
| 29. |
709
|
[2] |
GROMMET
|
NH
|
