纽荷兰零件查询(DC150.B) - CRAWLER DOZER TIER 2 (3/03-) (0.540[01]) - DRY AIR CLEANER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
730 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76093542 | [1] | RING | LEC |
| 2. | 76093544 | [1] | RIGID TUBE,101.6 mm OD, 226, 102 mm Length | LEC |
| 3. | 79098801 | [1] | AIR CLEANER | LEC- ASSY 12" SEE PAG.2 |
| 4. | 79106929 | [2] | BRACKET | LEC |
| 5. | 76076960 | [1] | INTAKE AIR HOSE,127.00 mm ID, 138.00 mm ID x 116.00 mm | LEC |
| 6. | 11106431 | [12] | SCREW,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 9515003 |
| 7. | 11701721 | [4] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 8. | 71421022 | [2] | HOSE CLAMP,114.3mm - 123.2mm | LEC |
| 9. | 16044031 | [2] | BOLT,Hex, M8 x 1.25 x 40mm, Cl 10.9 | LEC Superseded by part number: 9780069 |
| 10. | 16100821 | [2] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 11. | 73042943 | [1] | DUST VALVE | LEC |
| 13. | 76046298 | [1] | AIR PRE-CLEANER ASSY | LEC Superseded by part number: 75248762 |
| 15. | 76079342 | [2] | HOSE CLAMP | LEC |
| 16. | 14496631 | [8] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 17. | 76093543 | [1] | HOSE | LEC |
| 18. | 12626231 | [8] | WASHER,10.2mm ID x 25mm OD x 3mm Thk | LEC |
