| 1. |
86631464
|
[2] |
BRACKET
|
NH
|
| 2. |
746294
|
[2] |
LAMP REFLECTOR
|
NH
Red Superseded by part number: 80746294, 80746294, BER746294
|
| 3. |
86631462
|
[1] |
BRACKET
|
NH
|
| 4. |
84037090
|
[1] |
TAIL LAMP,12V, 21W, Amber/Red
|
ZED
Red
|
| 5. |
258985
|
[1] |
GROMMET
|
PA
Plastic Tube Superseded by part number: 86632155
|
| 6. |
263117
|
[13] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
CABLE STRAP
|
| 7. |
515-23127
|
[9] |
CLAMP,1/2", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 86010402
|
| 8. |
86618111
|
[1] |
WIRE HARNESS
|
NH
Lighting
|
| 9. |
86610201
|
[4] |
INSERT,M8
|
NH
Threaded, M8
|
| 10. |
84037093
|
[1] |
TAIL LAMP,12V, 21W, Amber/Red
|
ZED
Clear
|
| 11. |
86631486
|
[1] |
BRACKET
|
NH
|
| 12. |
853764
|
[4] |
CLAMP,7.9mm, Coat, 8.7mm Bolt Hole, P Type
|
NH
|
| 13. |
86618112
|
[1] |
WIRE HARNESS
|
NH
LH Extension
|
| 14. |
86615932
|
[2] |
BRACKET
|
NH
Superseded by part number: 87370803
|
| 15. |
799266
|
[2] |
LAMP REFLECTOR
|
NH
White
|
| 16. |
470016
|
[2] |
BULB
|
NH
12V, 10W Superseded by part number: E35556
|
| 17. |
336483
|
[2] |
POSITION LAMP
|
NH
LIGHT, TAIL
|
| 18. |
435895
|
[4] |
REFLECTOR,80mm OD, Orange
|
NH
Yellow, Pickup LH & RH
|
| 19. |
529070
|
[2] |
CABLE TIE,368.3mm L
|
NH
CABLE STRAP
|
| 20. |
86614960
|
[1] |
WIRE HARNESS
|
NH
Main
|
| 21. |
418870
|
[2] |
BULB,12V, 10W
|
NH
12V, 10W Superseded by part number: 14149590
|
| 22. |
398877
|
[4] |
BULB,12V, 21W
|
NH
Superseded by part number: 14148190
|
| 24. |
84461
|
[4] |
SCREW,Slotted Truss Hd, #10 - 24 x 5/8"
|
NH
|
| 25. |
9706703
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
NH
|
| 26. |
844-8020
|
[8] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 27. |
811-8020
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 28. |
577927
|
[2] |
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
3/4", 13/32" Bolt
|
| 29. |
825-2406
|
[7] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 30. |
825-2408
|
[9] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 31. |
825-1404
|
[4] |
NUT,M4, Cl 8
|
CAS
Superseded by part number: 57121
|
| 33. |
88826
|
[4] |
LOCK NUT,#10-24, GA
|
NH
|
| 34. |
844-6020
|
[1] |
BOLT,Hvy Hex, M6 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804256
|
| 35. |
322357
|
[7] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 36. |
322358
|
[10] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 37. |
492-11008
|
[4] |
LOCK WASHER,#8
|
CAS
Superseded by part number: 87812
|
| 38. |
492-11010
|
[2] |
LOCK WASHER,#10
|
CAS
Superseded by part number: 80684
|
| 39. |
495-31022
|
[6] |
WASHER,#10
|
CAS
Superseded by part number: 88612
|
| 40. |
86979734
|
[2] |
CLIP
|
BEL
|
| 41. |
86618113
|
[1] |
WIRE HARNESS
|
NH
|
| 42. |
84821
|
[2] |
SCREW,Truss HD, #10 - 24 x 1/2"
|
NH
|
| 43. |
225-14110
|
[2] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 44. |
677808
|
[1] |
SELF-TAP SCREW,Hex Flng, 1/4" - 20 x 5/8"
|
NH
HWH, 1/4"-20 x 5/8"
|
| 45. |
570821
|
[2] |
SELF-TAP SCREW,Hex Flng, 5/16" - 18 x 5/8"
|
NH
Flg, USR, 5/16"-18 x 5/8"
|
