现代零件查询20/25BRJ-7 FORK & EXTENSION FORK(OPT, 25BRJ)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
171 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 21. |
64HK-12010G
|
[2] |
FORK ASSY(1000)
|
|
| 21. |
64HK-12020G
|
[2] |
FORK ASSY (1050)
|
|
| 21. |
64HK-12030G
|
[2] |
FORK ASSY(1200)
|
|
| 21. |
64HK-12040G
|
[2] |
FORK ASSY(1350)
|
|
| 21. |
64HK-12050G
|
[2] |
FORK ASSY(1500)
|
|
| 21. |
64HK-12060G
|
[2] |
FORK ASSY(1650)
|
|
| 21. |
64HK-12070G
|
[2] |
FORK ASSY(1800)
|
|
| 21-1. |
H200
|
[1] |
PIN KIT
|
|
| N21-11. |
H501
|
[1] |
KNOB
|
|
| N21-12. |
H502
|
[1] |
SPRING PIN
|
|
| N21-13. |
H503
|
[1] |
SPRING
|
|
| N21-14. |
H504
|
[1] |
PIN
|
|
| 22. |
69FG-83010
|
[2] |
EXT FORK ASSY(1500)
|
|
| 22. |
69FG-83020
|
[2] |
EXT FORK ASSY(1700)
|
|
| 22. |
69FG-83030
|
[2] |
EXT FORK ASSY(1800)
|
|
| N22-1. |
69FG-83100
|
[1] |
EXT FORK (1500)
|
|
| N22-1. |
69FG-83200
|
[1] |
EXT FORK (1700)
|
|
| N22-1. |
69FG-83300
|
[1] |
EXT FORK (1800)
|
|
| 22-2. |
69FG-83500
|
[1] |
LOCKING PIN
|
|
| 22-3. |
S037-102026
|
[1] |
BOLT-W/WASHER
|
|
