神钢零件查询(F4GE9484C J602) - ENGINE 504242281 - 84473213 (1/14-) (10.304.01[01]) - PUMP, ENGINE OIL & RELATED PARTS (2853406 - 2852120) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
118 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2A. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 3. | 4895406 | [1] | EXPANSION PLUG,9.8mm OD | TOR |
| 4. | 4897330 | [2] | HEX SOCKET PLUG,M12 x 1.5 | TORASSY |
| 4A. | NSS | [2] | NOT SOLD SEPARAT | CON |
| 5. | 4895610 | [1] | O-RING,2.2mm Thk x 9.3mm ID | TOR |
| 7A. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 9. | 2852134 | [2] | FLANGE BOLT,Hex, M12 x 1.75 x 25mm | TOR Superseded by part number: 16677735 |
