| 1. |
9512522
|
[2] |
SUPPORT
|
PA
Reservoir Superseded by part number: 87028121
|
| 2. |
87015766
|
[1] |
AIR RESERVOIR
|
PA
Superseded by part number: 87015668
|
| 3. |
9512530
|
[11] |
WASHER, THRUST,22mm ID x 27mm OD x 2.6mm Thk
|
PA
Superseded by part number: 3076153R1
|
| 4. |
9512529
|
[11] |
O-RING
|
PA
|
| 5. |
9512527
|
[8] |
FERRULE
|
PA
|
| 6. |
9512525
|
[4] |
ELBOW
|
PA
|
| 7. |
87359227
|
[1] |
PLASTIC-RUBBER TUBE,10000.00 mm
|
PA
Nylon
|
| 8. |
87012161
|
[2] |
BRACKET
|
PA
|
| 9. |
87012533
|
[2] |
PLATE
|
PA
|
| 10. |
87389513
|
[1] |
HOSE,3.00 mm ID x 500.00 mm
|
PA
|
| 11. |
326082
|
[4] |
CLAMP,18mm - 25mm
|
ZED
|
| 12. |
9512534
|
[2] |
HYD CONNECTOR
|
PA
|
| 13. |
9512531
|
[2] |
HYD CONNECTOR
|
PA
|
| 14. |
9512546
|
[1] |
COUPLING BLOCK
|
PA
|
| 15. |
9512537
|
[1] |
COUPLING BLOCK
|
PA
|
| 16. |
9512545
|
[2] |
AIR FILTER
|
PA
|
| 17. |
84007187
|
[1] |
CYLINDER
|
PA
|
| 18. |
87023509
|
[1] |
SUPPORT
|
PA
|
| 19. |
9512528
|
[2] |
HYD CONNECTOR
|
PA
|
| 20. |
84007190
|
[1] |
ELBOW,M16 x 1.5 Male
|
ZED
Coupling
|
| 21. |
9512532
|
[1] |
O-RING
|
PA
|
| 22. |
9512533
|
[1] |
WASHER, THRUST,16.1mm ID x 22mm OD x 2.6mm Thk
|
PA
|
| 23. |
9512523
|
[3] |
PLUG
|
PA
|
| 24. |
84007189
|
[1] |
HYD CONNECTOR,M22 x 1.5
|
ZED
Straight Male
|
| 25. |
87019852
|
[1] |
BRAKE VALVE
|
PA
|
| 26. |
87023510
|
[1] |
SUPPORT
|
PA
|
| 27. |
844-8020
|
[3] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 28. |
844-10050
|
[2] |
BOLT,Hvy Hex, M10 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 16587625
|
| 30. |
9512540
|
[1] |
HYD CONNECTOR
|
PA
Superseded by part number: 443287A1
|
| 31. |
9512541
|
[1] |
DRAIN PLUG
|
PA
|
| 32. |
322358
|
[7] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 33. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 35. |
832-46410
|
[4] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 36. |
825-2408
|
[7] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 37. |
825-2410
|
[2] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 38. |
86974526
|
[1] |
HOSE,9.53mm ID x 1625.6mm L, SAE 100R1
|
PA
|
| 39. |
87019827
|
[1] |
HOSE,0.38" ID x 79.00", SAE 100R1
|
PA
|
| 40. |
515-23127
|
[1] |
CLAMP,1/2", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 86010402
|
| 41. |
814-10080
|
[4] |
BOLT,Hex, M10 x 1.5 x 80mm, Cl 8.8
|
CAS
Superseded by part number: 129796A1
|
| 42. |
84007191
|
[1] |
ADAPTER,9/16" - 18 JIC x M12 x 1
|
ZED
|
| 43. |
84011379
|
[1] |
SEAL,12.2mm ID x 16.9mm OD x 1.5mm Thk
|
ZED
SEALRING 12 x 17
|
| 44. |
9837647
|
[1] |
ELBOW,90 Degree - 9/16" - 18 JIC 37 Degree x 3/8" BSPP
|
PA
90° Superseded by part number: 89837647
|
| 45. |
9837622
|
[1] |
HYD CONNECTOR,9/16" JIC x 3/8" BSPP
|
PA
|
| 46. |
218-836
|
[1] |
TEE,37 Degree, 9/16"-18 x 9/16"-18, Fem Sw Br
|
CAS
Superseded by part number: 86513014
|
| 47. |
88946
|
[1] |
SELF-TAP SCREW,Hex Hd, 1/4" x 3/4"
|
NH
|
| 49. |
263117
|
[1] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
CABLE STRAP
|
