| 1. |
87010841
|
[1] |
ANGLE
|
PA
RH Superseded by part number: 87644263, 87644262
|
| 2. |
87010764
|
[1] |
ANGLE
|
PA
LH Superseded by part number: 87644263, 87644262
|
| 3. |
87010727
|
[1] |
BAR
|
PA
Safety, 2366 mm Lg. Superseded by part number: 87645231
|
| 4. |
87023182
|
[1] |
STEP
|
PA
Superseded by part number: 87050286
|
| 5. |
86640703
|
[1] |
SUPPORT
|
NH
|
| 6. |
27310
|
[1] |
SPRING
|
NH
Superseded by part number: 87047744
|
| 7. |
86642808
|
[1] |
STEP
|
PA
|
| 10. |
86643129
|
[1] |
JACK
|
NH
Heavy Duty
|
| 11. |
263636
|
[2] |
ANTI-SKID STRIP
|
NH
|
| 15. |
87666417
|
[1] |
HITCH
|
NH
Ring
|
| 15. |
86627569
|
[1] |
HITCH
|
PA
Ring
|
| 16. |
86977230
|
[1] |
PLATE
|
NH
|
| 17. |
86619421
|
[1] |
ROD
|
NH
|
| 18. |
321204
|
[2] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 19. |
814-16120
|
[3] |
BOLT,Hex, M16 x 2 x 120mm, Cl 8.8
|
CAS
Superseded by part number: 321246
|
| 20. |
844-6030
|
[2] |
BOLT,Hvy Hex, M6 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86511839
|
| 22. |
844-10030
|
[6] |
BOLT,Hvy Hex, M10 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 9840672
|
| 23. |
844-10050
|
[2] |
BOLT,Hvy Hex, M10 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 16587625
|
| 24. |
844-12030
|
[4] |
BOLT,Hvy Hex, M12 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 9670066
|
| 25. |
811-12025
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 374895
|
| 26. |
87017977
|
[1] |
PLATE
|
PA
|
| 27. |
130358
|
[6] |
WASHER,16.28mm ID x 38.35mm OD x 4.11mm Thk
|
NH
|
| 28. |
495-21050
|
[6] |
WASHER,7/16"
|
CAS
Superseded by part number: 81541
|
| 30. |
140045
|
[8] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 31. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 33. |
825-2406
|
[2] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 35. |
825-2410
|
[6] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 36. |
9804279
|
[4] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 38. |
832-46410
|
[2] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 39. |
832-46412
|
[2] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 100038
|
| 40. |
832-46416
|
[6] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 86000441
|
| 42. |
87040646
|
[1] |
SUPPORT ASSY.
|
PA
|
