| 1. |
86635754
|
[1] |
SPRING,Compression, 1.029" OD x 2.73" L
|
NH
|
| 2. |
80707372
|
[1] |
BRACKET
|
NH
Superseded by part number: 86636168
|
| 3. |
9621054
|
[1] |
CLUTCH ASSEMBLY
|
PA
Superseded by part number: 87660307
|
| 4. |
86621149
|
[2] |
CHAIN,60, 57 Links x 19.05mm = 1085.85mm
|
NH
RC606, 57 Total Links, Includes: Ref. 40 & 41
|
| 5. |
86610109
|
[1] |
SPROCKET
|
NH
Superseded by part number: 87660330
|
| 6. |
633743
|
[1] |
SPACER
|
NH
|
| 7. |
86627639
|
[1] |
SPROCKET,15T
|
NH
15T
|
| 8. |
86615181
|
[1] |
ARM
|
NH
Includes: Ref. 16
|
| 9. |
590224
|
[1] |
SPACER,41/64” ID x .875” OD x 13/32” Wide
|
PA
Superseded by part number: 87020989
|
| 10. |
86615228
|
[1] |
STRAP
|
NH
Linkage
|
| 11. |
86643094
|
[1] |
INDICATOR
|
NH
|
| 12. |
9825987
|
[1] |
BUSHING,76.2mm ID x 82.68mm OD x 9.86mm L
|
NH
|
| 13. |
614-10035
|
[2] |
BOLT,Hex, M10 x 1.5 x 35mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 9706704
|
| 14. |
9804273
|
[1] |
BOLT,Hex, M16 x 60mm, Cl 8.8
|
NH
|
| 15. |
9808110
|
[3] |
WASHER,46mm ID x 60mm OD x 1.64mm Thk
|
NH
Hardened, M45
|
| 16. |
399994
|
[1] |
BUSHING,20mm ID x 23mm OD x 25mm L
|
NH
|
| 17. |
86624647
|
[2] |
WASHER,10.8mm ID x 57mm OD x 6.1mm Thk
|
NH
|
| 18. |
86627126
|
[1] |
WASHER,29.18mm ID x 51.56mm OD x 2.03mm Thk
|
NH
2" OD
|
| 19. |
27367
|
[1] |
WASHER,16.67mm ID x 31.75mm OD x 3.43mm Thk
|
NH
21/32"ID x 1-1/4" OD
|
| 20. |
495-11081
|
[1] |
WASHER,3/4", SAE
|
CAS
Superseded by part number: 87381
|
| 21. |
495-21044
|
[1] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 22. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 23. |
140048
|
[1] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 26. |
825-1410
|
[2] |
NUT,M10, Cl 8
|
CAS
Superseded by part number: 100016
|
| 27. |
825-2416
|
[1] |
FLANGE NUT,M16 x 2, Flg, Cl 8
|
CAS
|
| 31. |
170015
|
[1] |
KEY,12mm x 8mm x 32mm
|
NH
Superseded by part number: 80353711
|
| 32. |
126-124
|
[1] |
WOODRUFF KEY,#15, 1/4" x 1", HT
|
CAS
Superseded by part number: 47471
|
| 33. |
87017555
|
[1] |
DRIVEN SPROCKET
|
PA
28T, Includes: Ref. 12
|
| 34. |
86636779
|
[1] |
HUB
|
NH
|
| 35. |
127434
|
[2] |
DISC,77.7mm ID x 146mm OD x 3.56mm Thk
|
NH
Clutch
|
| 36. |
86627129
|
[1] |
CLUTCH PLATE
|
NH
|
| 37. |
121092
|
[2] |
BELLEVILLE WASHER,35mm ID x 117.5mm OD x 3.5mm Thk
|
NH
|
| 38. |
414-620
|
[3] |
BOLT,Hex, 3/8" - 24 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 86631589
|
| 39. |
144819C91
|
[1] |
BEARING
|
IH
Superseded by part number: 149261C91
|
| 40. |
86595275
|
[1] |
OFFSET LINK
|
ZED
Superseded by part number: 241-1716
|
| 41. |
165590
|
[1] |
CONNECTING LINK
|
PA
Superseded by part number: 241-1316
|
