神钢零件查询(F4GE9484D J601) - ENGINE - 5801370290 - 84301930.. (1/07-12/07) (0610.020) - CYLINDER HEAD Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
304 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4892861 | [4] | CAPTIVE WASHER SCREW,Wash Hd, M12 x 1.75 x 73 | TORHEXAGON BOLT, M15X1,75 |
| 2. | 4892859 | [10] | BOLT,Flng, M12 x 1.75 x 143mm | TORHEXAGON BOLT, M15X1,75 |
| 3. | 504226952 | [1] | CYLINDER HEAD | SPARE PART |
| 4. | 4895183 | [16] | COLLET | TORVALVE CONE |
| 5. | 4899632 | [4] | STD EXHAUST VALVE | TOREXHAUST VALVE |
| 6. | 4895187 | [4] | STD INLET VALVE | TORINLET VALVE |
| 7. | 4895347 | [8] | SEAL | TORCAP |
| 8. | 4895215 | [8] | VALVE SPRING,Compression, 32.8mm OD x 63.5 mmL | TORENGINE VALV.SPRING |
| 9. | 4895184 | [8] | RETAINER,34mm OD, 10.63mm ID, 14.5mm L | TORSPRING CAP |
| 10. | 2830919 | [1] | CYLINDER HEAD GASKET,1.4mm Thk | TORCYL.HEAD GASKET |
| 11. | 4897179 | [4] | VALVE SEAT,38 mmID x 47mm OD x 6.9mm L | TORVALVE SEAT STD., EXHAUST |
| 12. | 4895179 | [3] | EXPANSION PLUG,M20.93 | TORLOCK PLUG |
| 13. | 4897178 | [4] | VALVE SEAT,36mm ID x 43mm OD x 6.7mm L | TORVALVE SEAT STD., INTAKE |
| 14. | 4895085 | [1] | EXPANSION PLUG,25.74mm | TORPLUG |
