现代零件查询22/25/30/32B-7 SEATEPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
835 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 8. |
S403-082006
|
[4] |
WASHER-PLAIN
|
|
| 24. |
S275-080006
|
[4] |
NUT-SELF LOCKING
|
|
| 28. |
71FH-10511
|
[1] |
SEAT ASSY(PKT)
|
|
| 28. |
71FH-10521
|
[1] |
SEAT ASSY(PKT+BT)
|
|
| 28. |
71FH-10531
|
[1] |
SEAT ASSY(PKT+BT+HR)
|
|
| 28. |
71FH-10541
|
[1] |
SEAT ASSY(PKT+BT+AR)
|
|
| 28. |
71FH-10550
|
[1] |
SEAT ASSY(PKT+BT+HR)
|
|
| 28. |
71FH-10560
|
[1] |
SEAT ASSY(PKT+BT+AR)
|
|
| 28. |
F12120300
|
[1] |
SEAT ASSY(PKT)
|
|
| 28-A. |
310006540
|
[1] |
SWITCH-SEAT
|
|
| 28-B. |
B51800050
|
[1] |
HARNESS-SEAT
|
|
| 28-1. |
H31013-100C
|
[1] |
CUSHION ASSY
|
|
| 28-2. |
H31013-200B
|
[1] |
BACK ASSY
|
|
| 28-3. |
H31013-360
|
[1] |
SHOCK ABSORBER ASSY
|
|
| 28-4. |
H31013-600B
|
[1] |
SLIDE TRACK ASSY
|
|
| 28-5. |
89890-8A610
|
[1] |
BELT-SEAT
|
|
| 28-6. |
H31023-301G
|
[1] |
SUSPENSION
|
|
| 28-8. |
H31010-500
|
[1] |
ARM RESTRAINT-LH
|
|
| 28-9. |
H31015-500
|
[1] |
ARM RESTRAINT-RH
|
|
| 28-10. |
H31010-700
|
[1] |
HIP RESTRAINT-LH
|
|
| 28-11. |
H31015-700
|
[1] |
HIP RESTRAINT-RH
|
|
| 28-12. |
71FH-10590
|
[1] |
KNOB-RECLINER
|
|
