凯斯零件查询(RBX452) - CASE IH ROUND BALER (11/02-7/05) (12.46) - JACK, HEAVY DUTY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
266 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86620971
|
[1] |
RING
|
NH
|
| 2. |
86636799
|
[2] |
SPACER,10.3mm ID x 19.05mm OD x 19.05mm L
|
NH
|
| 3. |
86620973
|
[1] |
STRAP
|
NH
|
| 4. |
86643129
|
[1] |
JACK
|
NH
Heavy Duty
|
| 5. |
86627939
|
[2] |
CLAMP
|
NH
|
| 6. |
86628108
|
[2] |
SPRING
|
NH
|
| 7. |
86627946
|
[1] |
U-BOLT
|
NH
Special, M6 x 1, Threaded
|
| 10. |
844-8020
|
[4] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 11. |
825-2406
|
[2] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 12. |
825-2408
|
[4] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 13. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 14. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 15. |
87035356
|
[1] |
PIN ASSY.,15.88mm OD
|
PA
Pull 5/8" Superseded by part number: 87049997
|
