日立零件查询（AR2000）LIGHTING (PH) Hitachi HOP online
广数供应链运营团队, 14 02月, 2025，浏览：
525 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 00. | Y403961 | [2] | LAMP;HEAD | |
| 01. | Y411503 | [2] | BRACKET | |
| 02. | J901430 | [6] | BOLT | |
| 03. | A590114 | [6] | WASHER;PLANE | |
| 06. | 4336570 | [4] | LAMP;HEAD | |
| 06A. | 4326801 | [1] | LENS;UNIT | |
| 06B. | 4326802 | [1] | FRAME | |
| 06C. | 4285648 | [1] | BULB | |
| 06D. | 4326803 | [1] | GASKET | |
| 06E. | 4307026 | [1] | WASHER | |
| 06F. | 4307027 | [1] | SCREW | |
| 06G. | A590114 | [1] | WASHER;PLANE | |
| 06H. | A590914 | [1] | WASHER;SPRING | |
| 06I. | J952014 | [1] | NUT | |
| 07. | 4224631 | [4] | BRACKET | |
| 10. | 4426886 | [3] | LAMP | |
| 11. | Y414842 | [3] | RUBBER | |
| 12. | Y415136 | [3] | RUBBER | |
| 13. | Y415170 | [3] | COVER | |
| 14. | A590104 | [6] | WASHER;PLANE | |
| 15. | A590904 | [6] | WASHER;SPRING | |
| 16. | M500403 | [6] | NUT | |
