现代零件查询22/25/30/32B-7 CABIN 1EPC Hyundai _现代Hyundai_工程机械

现代零件查询22/25/30/32B-7 CABIN 1EPC Hyundai

广数供应链运营团队, 14 02月, 2025，浏览： 213 次

Pos.	Part No	Qty	Parts name	Comments
1.	71FH-52001	[1]	CABIN WA	22/25B(-7)
1.	71FH-53001	[1]	CABIN WA	30/32B(-7)
2.	71FH-52011	[1]	FRONT ASSY
2-1.	71FH-52980	[1]	COVER
2-2.	71FH-52620	[1]	GLASS-FRONT,WINDOW
2-3.	S781-238002	[1]	SEAL-GLASS
2-4.	21M7-30310	[1]	MOTOR-WIPER
2-5.	21M6-52050	[1]	ARM-WIPER
2-6.	21M6-52060	[1]	BLADE-WIPER
2-8.	S772-010500	[1]	WEATHER STRIP
2-9.	S035-082026	[4]	BOLT-W/WASHER
7.	71FH-52062	[1]	TOP SUB ASSY	22/25B(-7)
7.	71FH-53062	[1]	TOP SUB ASSY	30/32B(-7)
7-1.	21EH-0011	[1]	LAMP-ROOM
7-2.	71FH-52920	[1]	GLASS-TOP	22/25B(-7)
7-2.	71FH-53400	[1]	GLASS-TOP	30/32B(-7)
7-3.	71FH-52951	[1]	HEADLINING	22/25B(-7)
7-3.	71FH-53412	[1]	HEADLINER	30/32B(-7)
7-4.	71FH-52991	[1]	COVER WA
7-5.	71FH-53610	[2]	PLATE
7-6.	71HD-51202	[2]	HINGE
7-7.	71HD-51390	[1]	LOCK HANDLE
7-8.	71HD-51491	[1]	PLATE WA-CASSETTE
7-9.	71HD-51523	[1]	COVER
7-10.	71HD-51531	[1]	COVER
7-11.	S132-061556	[14]	SCREW-W/WASHER
7-12.	S035-062026	[4]	BOLT-W/WASHER
7-13.	S403-06200B	[2]	WASHER-PLAIN
7-14.	S131-051546	[12]	SCREW-W/WASHER
7-15.	S203-06100B	[2]	NUT-HEX
7-16.	S771-017750	[1]	WEATHER STRIP
7-17.	S781-128602	[1]	SEAL-GLASS	22/25B(-7)
7-17.	S781-131802	[1]	SEAL	30/32B(-7)
8.	71FH-52071	[1]	REAR ASSY
8-1.	71FH-52721	[1]	COVER
8-2.	71FH-52742	[1]	GLASS-REAR
8-3.	71FH-52770	[6]	CUSHION
8-4.	71FH-52840	[1]	BAR-HANDDLE
8-5.	71FH-52861	[2]	HINGE
8-6.	71FH-52870	[2]	RUBBER
8-7.	71FH-52880	[2]	PIN-HINGE
8-8.	71HD-51390	[1]	LOCK HANDLE
8-9.	71M6-51820	[2]	GAS SPRING
8-10.	S035-062036	[4]	BOLT-W/WASHER
8-11.	S403-08200B	[7]	WASHER-PLAIN
8-12.	S771-033500	[1]	WEATHER STRIP
8-13.	S772-009500	[1]	WEATHER STRIP
8-14.	71FH-54060	[2]	SPONGE
8-15.	S203-08100B	[6]	NUT-HEX
8-16.	71FH-53840	[1]	SPONGE
