现代零件查询22/25/30/32B-7 LIFT CYLINDER(TF-MAST, 32B, OLD)EPC Hyundai _现代Hyundai_工程机械

现代零件查询22/25/30/32B-7 LIFT CYLINDER(TF-MAST, 32B, OLD)EPC Hyundai

广数供应链运营团队, 14 02月, 2025，浏览： 123 次

Pos.	Part No	Qty	Parts name	Comments
.	33HA-07101	[2]	LIFT CYLINDER ASSY	TF370
.	33HA-07111	[2]	LIFT CYLINDER ASSY	TF400
.	33HA-07121	[2]	LIFT CYLINDER ASSY	TF430
.	33HA-07131	[2]	LIFT CYLINDER ASSY	TF450
.	33HA-07141	[2]	LIFT CYLINDER ASSY	TF470
.	33HA-07151	[2]	LIFT CYLINDER ASSY	TF500
.	33HA-07161	[2]	LIFT CYLINDER ASSY	TF550
.	33HA-07171	[2]	LIFT CYLINDER ASSY	TF600
.	33HA-07181	[2]	LIFT CYLINDER ASSY	TF650
1.	XKCD-00025	[1]	TUBE ASSY	TF370
1.	XKCD-00030	[1]	TUBE ASSY	TF400
1.	XKCD-00032	[1]	TUBE ASSY	TF430
1.	XKCD-00173	[1]	TUBE ASSY	TF450
1.	XKCD-00175	[1]	TUBE ASSY	TF470
1.	XKCD-00034	[1]	TUBE ASSY	TF500
1.	XKCD-00037	[1]	TUBE ASSY	TF550
1.	XKCD-00040	[1]	TUBE ASSY	TF600
1.	XKCD-00043	[1]	TUBE ASSY	TF650
2.	XKCD-00026	[1]	ROD	TF370
2.	XKCD-00031	[1]	ROD	TF400
2.	XKCD-00033	[1]	ROD	TF430
2.	XKCD-00174	[1]	ROD	TF450
2.	XKCD-00176	[1]	ROD	TF470
2.	XKCD-00035	[1]	ROD	TF500
2.	XKCD-00038	[1]	ROD	TF550
2.	XKCD-00041	[1]	ROD	TF600
2.	XKCD-00044	[1]	ROD	TF650
3.	XKCD-00027	[1]	PISTON
K4.	Y400-055000	[1]	SEAL-PISTON
K5.	Y180-045020	[1]	RING-BACK UP
K6.	Y310-055100	[1]	RING-WEAR
7.	31YC-99G20	[1]	RING-RETAINING
8.	31YC-99F60	[1]	SEAL-CUSHION
9.	31YC-99F70	[1]	RING-RETAINING
10.	XKCD-00028	[1]	SPACER	TF370-TF430
10.	XKCD-00036	[1]	SPACER	TF450-TF500
10.	XKCD-00039	[1]	SPACER	TF550
10.	XKCD-00042	[1]	SPACER	TF600
10.	XKCD-00045	[1]	SPACER	TF650
K11.	S632-040004	[1]	O-RING
12.	XKCD-00005	[1]	STOPPER
13.	S731-045030	[1]	BUSHING-DU
14.	XKCD-00004	[1]	GLAND
K15.	Y270-045011	[1]	SEAL-ROD
K16.	Y120-045011	[1]	WIPER-DUST
K17.	S632-060004	[1]	O-RING
K.	31Y3-30280	[1]	SEAL KIT	SEE ILLUST
